Chapter 1. Introduction

This guide is for 9600 Series telephones supported by an Avaya IP Office telephone system running in IP Office Essential Edition, Preferred Edition, Advanced Edition, or Server Edition mode.

1.10 Button Modules

The addition of a button module allows the phone to support additional programmable buttons.

Do not connect or disconnect a button module yourself. Your system administrator will arrange this if necessary. Failure to connect and restart the equipment in the correct order may cause the phone and or the button module to function incorrectly.

9608 and 9641 Phones

These phones support BM12 button modules. Each button module provides the phone with an additional 24 buttons (2 pages of 12) which can be used as appearance buttons and or feature buttons. For IP Office Release 9.0, this phone can also support SBM24 modules instead (see below) but not a mix of different module types.

Up to three button modules can be attached to each phone. However, the number of button modules supported by the telephone system may be limited by the total number of button modules attached to other phones on the telephone system.

9630, 9640, and 9650 Phones

All variants of these phones support SBM24 button modules. Each button module provides the phone with an additional 24 buttons which can be used as appearance buttons and or feature buttons. Up to three button modules can be attached to each phone. However, the number of button modules supported by the telephone system may be limited by the total number of button modules attached to other phones on the telephone system.

9620 Phones and 9621 Phones

These phones do not support any additional button modules.

1.11 Phone Keys

The following keys are found on the phone:

Soft Keys – The keys below the display have variable functions. When the key is active, its function is indicated by the text label above it. On touch screen phones the labels on the screen can be pressed.
Message – This key is used to access your voicemail system. By default, this uses a series of menus on your phone’s display.
Navigation Keys – Press the up and down arrow keys to scroll through lists. In some menus, you can also use the left and right arrow keys to enter and exit different levels of the menu. A menu option that accesses a sub-menu is indicated by the … dots (ellipsis) icon after its name.
OK – The OK key normally matches the function offered by the leftmost soft key below the screen.
PHONE – This key is used to exit any menu you are in and return to the appearance buttons menu. During a call it can also be used to toggle the options displayed on the appearance menu.
MENU/HOME – This key is used to access a menu for phone settings and information.
CONTACTS – This key is used to display the various directories (personal and shared) of names and telephone numbers to which you have access.
CALL LOG / HISTORY – This key displays a record of your most recent calls (answered, missed, and outgoing). The button is illuminated when you have new missed calls.
VOLUME – Press + plus or – minus on the Volume key to adjust the volume of the incoming call. Separate volumes can be adjusted for the ringer, handset, headset, and speaker.
HEADSET – This key is used to answer and end calls using a headset connected to the phone’s headset socket. The button is lit when you are connected to a call using the headset.
MUTE – This key can be used to mute your speech to the currently connected call. The button is lit while mute is active.
SPEAKER – This key is used to answer and end calls using the phone’s handsfree speaker and microphone. The button is lit when you are connected to a call handsfree.
FORWARD – This button provides direct access to the forwarding menu options. This button is not present on the 9620 and 9650 models.
Appearance Keys – These buttons represent calls that you can make or receive.
Feature Buttons – Those keys not configured as appearance keys can be used for other functions. On touch screen phones, these buttons are replaced by their text labels on the screen.
The CONFERENCE, DROP, HOLD, REDIAL and TRANSFER keys found on other Avaya phones are presented as a soft key functions relative to the current call.

1.12 Status Letters

When your own extension name is shown on the second line of the display, for example when the phone is idle, the name may be followed by a series of letters. These letters are used to indicate your current status.

B = Barred
A B is shown on your phone’s display when the system administrator has prohibited you from making outgoing calls. You will only be able to make internal calls when your status is set to Barred.
D = Diverting (Forwarding) Calls
A D is shown after your extension name on the phone’s idle display when you have ‘forward unconditional’
enabled.
G = Group Member (In Group)
A G is shown after your extension name on the phone’s idle display when you have been configured as a member of a hunt group and your membership is enabled. With this status active, you may receive calls targeted to the hunt group.
N = No Calls (Do Not Disturb)
An N is shown after your extension name on the phone’s idle display when you have ‘do not disturb’ enabled.
O = Out of Service
When a group is set tonight service mode, all members of that group retain an ‘out of service’ status indicated by an O on the idle display. Calls are diverted to the group’s fallback if set. Otherwise, the calls are sent to voicemail (if available).
R = Resilience
An R is shown after your extension name on the phone’s idle display to indicate that your phone is working in resilience mode. This is used when there may have been a problem with the telephone system to which your phone was registered and another system is currently providing support for your phone. In this mode, some features may not be available and calls may be routed differently.
S = System Alarm
If you are configured as a system administrator, an S in the phone’s display indicates a system alarm.
T = Twinned
A T is shown after your extension name on the phone’s idle display if it is internally twinned with your phone. Calls to you will alert on both phones and can be answered by you at either phone.

1.13 Touch Screen Operation

The 9621 and 9641 phones use touch-sensitive screens to replace many of the buttons required on other phones. These are pressure sensitive and can be operated with either your finger(s) or a stylus. However, you must take care not to use any device that may scratch or cause wear to the screen.

Unlike other phones in the range (where you need to highlight an option on the screen using the arrow keys and then select that option using the Select soft key), on a touch screen, you can simply press the required option directly.

1.14 The Phone Stand

The phones all include a stand that clips to the base of the phone. The stand allows the phone to be used in either of two
different angles.

When changing the position of the stand, be sure to check that the stand has locked into the chosen position. A small plastic peg is located just under the phone’s handset. This peg can be reversed to more securely anchor the handset when the stand places the phone in an upright position.

9608 Phones

The stand cannot be flipped to another position except by removing it to change the position. The angle of the display is not adjustable on these phones.

Other 9600 Phones

Once attached, the stand can be used in either position to change the angle of the phone. The angle of the phone can also be adjusted as shown below. The angle of the display can also be adjusted.

Chapter 2. Making Calls

If you are not already on a call, then you can just dial the number. The first available appearance button will be used for the call. Alternatively, you can press a specific appearance button in order to make a call using that button.

If the number you dial matches a user or group on the telephone system, the directory name of the user or group is shown and the call starts altering the target.

If the call is to a user, and they do not answer, you can set a callback by pressing CallBack and then ending the call by pressing Drop. When a callback is set, the next time a user uses their phone or ends their current call, the system will call you, and when you answer, automatically make another call to the user.

2.1 En-Bloc Dialing

By default, when you start dialing a number on your phone, the phone immediately connects to the telephone system and starts passing the digits you dial to the phone system. You cannot correct the digits you have already dialed except by ending the call and starting over. Also, if you pause dialing for too long the phone system may think that you have finished dialing and will attempt to connect the call using only the digits you had dialed up to that point.

En-bloc dialing allows you to compose and edit the number to dial on your phone’s display before it is sent to the phone system to be dialed.

Through the phone’s menus, you can select whether you want to use traditional or en-bloc dialing when making calls. Your chosen setting is then applied whenever you use a phone that supports en-bloc dialing.

Dialing a Number Using En-Bloc Mode

With no connected call on the phone, start dialing. Do not lift the handset or select headset or speaker before dialing.
You can use the left arrow key or the Bksp key to delete the previous digit dialed if you need to correct the number or press Clear to erase the whole number.
When you have completed the number, you can select how you want to make the call:
Lift the handset to make a call using the handset.
Press the Call soft key or OK button to start the call using the phone’s default handsfree audio path (speaker or headset). You can also press one of your idle call appearance buttons to make the call using that appearance.
Press the Headset button to start the call on a headset connected to your phone.
Press the Speaker button to start the call on your phone’s handsfree speaker.

Enabling/Disabling En-Bloc Dialing

You can enable or disable your en-bloc dialing setting through the phone’s Features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight En-Bloc Dial.
Use the Change button to select On or Off.

2.2 Call Soft Key Options

The options displayed for the buttons at the bottom of the display will change dynamically to reflect actions that you can perform during calls or while the phone is idle.

Some or all of these options will only be available if enabled by your system administrator.

Account
Enter an account code to associate with the call.
Answer
Answer a page call, turning it into a normal call.
CallBack
Set an automatic callback on the user that you have called but who has not answered. When they next end a call, the telephone system will call you and when answered, will automatically make a call to the user.
Complete
Complete the transfer of a held call. A Cancel option is also shown which will end the transfer attempt.
Conference
Put your current call on hold and present a dial tone for you to dial the number you want to add to a conference with the held caller.
Connect
Take a call off hold.
Dir
Access the directory in order to select a number by name rather than dial it. The type of names available in the directory is adjusted to match those suitable for use by the feature.
Drop
End the call.
Ignore
Quiet the ringer for the current alerting call. The call will continue alerting until either answered, it goes to voicemail, or the caller abandons the call.
Pickup
Answer the call that is held or alert another user.
Redial
If there are outgoing numbers in your call log, display the list of those numbers.
Transfer
Put your current call on hold and present a dial tone for you to dial the number to which you want to transfer the call.
ToVM
Send an alerting call to your voicemail.

2.3 Calling From the Contacts List

You can use any directory contact to make a call. You can also use the directory in almost any telephone function where you need to select the number for a destination, for example during a transfer.

Access the contacts directory:

a. Press the CONTACTS key. The directory menu is displayed.

b. Use the left and right arrow keys to select which type of directory entries you want to display.

All
All directory entries.
External
Directory entries are stored by the telephone system for all users to use.
Groups
The names and numbers of hunt groups on the telephone system.
Users
The names and numbers of other users on the telephone system.
Personal
Your own personal directory entries.

c. Use the up and down arrow keys to scroll through the list or start dialing the name you want to find to display only matching entries. If you dial a name to return to the full list press the Clear soft key.

d. To view more details of the highlighted name, press Details. To return to the directory press List.

2. When the required entry is highlighted, press Call or press the button next to the name.

Proceed as you would with a normally dialed call.

2.4 Calling From the Call Log/History

You can use the call log to make calls to the number included in the currently selected call record.

Access the call log.
a. Press the HISTORY button.
b. The display will change to show your call log records. The caller’s name is shown if known, otherwise the number. If you have any new missed call records, the button is illuminated and the call log will open showing your missed calls.

c. Use the left and right arrow keys to select which call log records you are viewing. The options are All, Outgoing, Incoming, and Missed. On touch screen phones, press the icon for the type of call log records you want to display.

d. Use the up and down arrow keys to scroll through the records.

Press Call to call the number displayed in the call record.

2.5 Redialling a Previous Number

When Redial is displayed it can be used in one of two ways, set by the phone’s redial mode setting.

List Mode
This redial method is used when your phone’s redial mode is set to List.

Access the redial list.
a. Press Redial. The list of outgoing calls is displayed.

b.Use the up and down arrow keys to scroll through the 10 most recent outgoing calls.

Press Call to call the number displayed in the call record.
Continue in the same way as for a normal dialed call.

One Number Mode
This redial method is used when your phone’s redial mode is set to One.

Press Redial.
The number for the most recent outgoing call in your personal call log is redialed.
Continue in the same way as for a normal dialed call.

2.6 Making a Page Call

In order to make page calls, you must have access to a paging shortcode provided by the system administrator or to a paging feature button. If the dialing short code or the paging button has been pre-configured with a number, the user or group at that number will be paged if available. The dialing shortcode can be configured to accept the number of the user or group to the page when dialed. Similarly, a paging button can be set to allow number entry when pressed as follows:

Press the paging button.
Dial the number of the user or group you want to page.
When the dialing is completed, the page call is made.

If the destination is a user and they already have a call connected, they cannot be paged. If the destination is a group which is not in service or has no available members, it cannot be paged.

Feature Button
If enabled by your system administrator, the self-administer function can be used to assign a feature button as a page button using the Group Paging action.

2.7 Withholding Your Number

You can select to withhold your number on external calls. Note that this option may not be supported in all situations. It may depend on the configuration of your phone system and options supported by your telephone line provider.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down menu keys to highlight Withhold Number.
Press Change to switch the option On or Off.
Press Save.

Access Control.
Your system administrator can configure whether you can access this menu option. See Menu Access Control.

2.8 Adjusting the Call Volume

While talking, you can adjust the volume of the incoming call. The volume is adjusted separately for whichever device is in use (handset, headset, or speaker).

With the call connected, press the VOLUME key.
Use the + plus and – minus keys to adjust the volume.
The display will return to normal after a few seconds.

2.9 Muting a Call

Muting a call stops the caller from hearing you. However, you can still hear them. The status indication line indicates a mute setting via the icon.

The mute setting remains active even if you switch between calls using hold and or appearance buttons.
If you change how you are listening to the call, for example switching from the handset to the speaker, the mute setting is canceled.

To activate mute, press the MUTE key. The button will be lit while mute is active.
To switch the mute off, press the MUTE key again.

2.10 Ending Calls

The Drop option can be used to end the currently highlighted call on the display.

If the call is connected to the phone’s speaker, the SPEAKER key is lit. Pressing the key again will end the call.
If the call is connected to the phone’s headset, the HEADSET key is lit. Pressing the key again will end the call.
If the call is connected to the phone’s handset, replacing the handset will end the call.

Chapter 3. Answering Calls

A slow flashing red lamp on an appearance button indicates an alerting call. This may also be accompanied by ringing
and by the message lamp flashing.

Selected Button

If you are currently not on a call, you can answer the alerting call in the following ways:

Select the method which you want to use to talk to the caller:

To quiet the ringing, press the Ignore soft key. The call will still continue alerting visually and can be answered or ignored.
To redirect the call to voicemail, press the To VM soft key.
To answer the call using the handset, lift the handset.
To answer the call handsfree, press the SPEAKER key.
To answer the call on a headset, press the HEADSET key.
Just pressing the call appearance key will answer the call either on the speaker or headset depending on the phone’s audio path setting.

Once you have answered the call, you can switch between different talk modes:

To switch to using the handset, lift the handset.
To switch to handsfree, press the SPEAKER key. If you were using the handset you can now safely replace it.
To switch to headset mode, press the HEADSET key. If you were using the handset you can now safely replace it.
If you have answered the call on the speaker or headset, pressing the SPEAKER or HEADSET key again before you select another mode will end the call.
Just pressing the call appearance key or any other appearance button will put the current call on hold.

Answering Another Call

If you are already on a call, answering a new call will automatically put the existing call on hold, unless your first press Drop.

Using the up and down arrow keys, scroll the display to highlight the waiting call.

To quiet the ringing, press the Ignore soft key. The call will still continue alerting and can be answered or ignored.
To redirect the call to voicemail, press the To VM soft key.

To answer the call, press the call appearance button. Your existing call will be put on hold.

Note
This guide assumes that auto hold is enabled (the default). The system administrator can disable auto hold for the system, in which case calls are automatically disconnected rather than held.

3.1 Diverting a Call to Voicemail

You can transfer a call targeted at you directly to your voicemail mailbox.

If the call is not the currently highlighted call on the display, use the up and down arrow keys to highlight it.
Press the To VM soft key. The call is redirected to your mailbox.

3.2 Ignoring an Incoming Call

You can quiet the ringer of a currently alerting call. The call will continue alerting visually but with no audible ring.

If the call is not the currently highlighted call on the display, use the up and down arrow keys to highlight it.
Press the Ignore soft key.
The call will continue alerting but with no audible ring.

3.3 Answering a Page Call

Your phone can be paged if you have no other connected call in progress. The page is heard through the phone’s speaker. This will only happen if your phone is currently idle.

A call connected automatically after a single beep is a page call directly to you or to a group of which your phone is a member. You can hear the caller but they cannot hear you.

A page call is indicated in the display by the word Page.
To answer the page call, press the Answer soft key. The call is turned into a normal call. You can continue handsfree or pickup the handset.
To ignore the page call, press the Drop soft key.

3.4 Using Call Pickup

Pickup is used to answer a call ringing elsewhere on the phone system.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Pickup. Press Select.

To answer a ringing call, press the Any soft key.
To answer a call ringing against a particular target, dial the target’s number. Alternatively, press the Dir soft key to select the target from the directory.

The following menus will appear depending on the type of number entered:

User Number

To answer a call ringing against the user, press the Pickup soft key.
To return to entering a number, press the Clear key.

Hunt Group Number
To answer a call ringing against the members of the group, press the Members soft key. The call does not have to be a call to the hunt group.
To answer a call ringing for the hunt group, press the Group soft key.
To return to entering a number, press the Clear key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

Default Short Codes

Shortcodes are numbers that you can dial to enable and disable various features. The following are default shortcodes that may be available. However, your system administrator can remove and change the shortcodes available to you or all users.

Pickup Any Call: *30
Answer a call ringing on the telephone system.
Pickup a Group Call: *31
Answer a call ringing a group of which you are a member. You can use this even if your group membership is currently set to disabled.
Pickup a Users Call: 32N#
Pickup a call ringing a user’s extension number (N).
Pickup a Group Members Call: 53N#
Pickup a call ringing the members of a group (N). This does not necessarily have to be a group call.

Chapter 4.Redialing

The phone’s redial operation can work in either of the following modes:

Open Call Log
If this mode is selected, pressing Redial will display a menu of the most recent outgoing calls in your call log. You can select the call that you want to redial and perform a number of other functions.
Last Dialed
If this mode is selected, pressing Redial will immediately repeat the most recent outgoing call in your call log. None of the other redial functions will be accessible.

You can select the redial mode that the phone uses. In either case, the redial function uses the outgoing call records in your personal call log. If you delete the records in your call log, redial will not work until new outgoing call records exist in your personal call log.

Note
Use of a centralized call log can be switched off by the system administrator. In that case the numbers used for the redial function are stored by the phone. This guide only covers redial using outgoing call records in the user’s centralized call log.

4.1 Open Call Log Mode

This redial method is used when your phone’s redial mode is set to List.

Access the redial list.
a. Press Redial. The list of outgoing calls is displayed.

b. Use the up and down arrow keys to scroll through the 10 most recent outgoing calls.

Press Call to call the number displayed in the call record.
Continue in the same way as for a normal dialed call.

4.2 Last Dialed Mode

This redial method is used when your phone’s redial mode is set to One.

Press Redial.
The number for the most recent outgoing call in your personal call log is redialed.
Continue in the same way as for a normal dialed call.

4.3 Selecting Your Redial Mode

You can select whether your phone uses the redial list or last call redial mode.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Redial Action.
The current mode, Open Call Log or Last Dialed is displayed.

Open Call Log
If this mode is selected, pressing Redial will display a menu of the most recent outgoing calls in your call log. You can select the call that you want to redial and perform a number of other functions.
Last Dialed
If this mode is selected, pressing Redial will immediately repeat the most recent outgoing call in your call log. None of the other redial functions will be accessible.

Press Change to change the mode.
When the desired mode is displayed, press Save.

Chapter 5. Holding and Parking Calls

5.1 Holding Calls

You can hold one or more calls.

The held call will still occupy the appearance button on which it was made or answered.
The caller will hear music on hold. If your system does not have music on hold available, the caller will hear double beep tones every few seconds.
If you have more than one held call, or one held call and a connected call, pressing the Conference soft key will start a conference between yourself and the calls.

Calls that you have held will return to your phone (when idle) if they remain on hold for too long. The default return delay is 15 seconds. Your hold recall can be changed by the system administrator. Returning calls ignore any forwarding or do not disturb settings.

Important – Holding Conference Calls

You can hold a conference call in the same way as holding a normal call. Holding the conference call does not affect the other conference parties who can continue talking. You will also still be listed as a member of the conference call in the conference details.

Warning: This only applies to conference calls hosted by your own telephone system. Holding your call to a conference hosted on another telephone system may cause that conference to hear your system’s music on hold.

5.1.1 Holding a Call

To put your current call on hold, press the Hold soft key or the call’s appearance button.
The held call will be indicated by its call appearance button with a fast-flashing green lamp. On phones with only a single call appearance button (or icon), the phone displays “On-Hold” before the call information on the call’s application line.
While held, the caller will hear music on hold. If your system does not have music on hold available, the caller will hear double beep tones every few seconds.
You can scroll the display using the up and down arrow keys. The held call will appear with a icon.

5.1.2 Taking a Call Off Hold

Either of the following methods can be used to retrieve a call from hold. If you have a currently connected call, that call will be automatically put on hold.

Press the appearance button with the fast-flashing red lamp call appearance.
Scroll the display using the up and down arrow keys, the held call will appear with a icon. Press the Connect soft key to take the call off hold.

5.1.3 Switching Between Calls

With a call on hold (fast-flashing appearance button) and another call connected (red call appearance button), you can switch between calls by pressing the appearance button of the held call. The current call is automatically put on hold and the previously held call is connected.

When you place a call on hold in order to make a transfer, the call is considered ‘on hold pending transfer’ and is indicated by fast-flashing red and green appearance buttons. On phones with only a single appearance button (or icon), the phone displays “On-Hold-Xfer” before the call information on the call’s application line.

5.1.4 Transferring a Held Call

There are various call transfer scenarios to consider:

If you have multiple calls on hold and you want to transfer a connected call to one of the held calls:

Press the Transfer soft key and use the up and down arrow keys to select the desired call appearance. When you are satisfied, press Complete to transfer the call while the other held call(s) remain on hold.

If you have calls on hold but you want to connect your current call with a new destination:

Press the Transfer soft key and enter the destination manually using the numerical keypad and press Complete. Alternatively, press Dir to select a destination from the directory or use the Redial option, if applicable.

If you have a destination call connected but you wish to refer back to the originating call before completing the transfer:

Do NOT press Complete to transfer the destination call as in scenario #2. Select the originating call (‘on hold pending transfer’) by pressing its call appearance button. This will place the destination call ‘on hold pending transfer’ so that you can notify the originating caller. With the originating call connected, you can now press Complete to connect the two calls. Held calls that are not pending transfer will not be affected. Moreover, it is not possible to have more than one call ‘on hold pending transfer.’

Note
It is also possible to transfer a held call by starting a conference and then dropping yourself from that conference. However, if you are the only internal user in the conference, depending on your telephone system’s configuration, dropping yourself might end the conference.

5.2 Parking Calls

Parking a call is similar to holding a call. However, parked calls can be unparked by other users on the phone system. Each parked call is given a number. By default, the number is your extension number plus a digit.

Calls that you park return to your phone (when idle) if they remain parked for too long. The default return delay is five minutes. This is a system delay that is applied to all users and can be changed by the system administrator. Returning calls ignore any forwarding or do not disturb settings.

A feature button set to the Call Park action can be used to park and unpark calls and to indicate parked calls.

Default Short Codes

Park Call: 37N#
Parks the held call using the park number dialed in place of N.
Unpark Call: 38N#
Unpark the call parked using the park number N.

5.2.1 Parking Calls Using the Menu

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Park or Call Park To Other.

Call Park
Park the call on the system with parked call indication on your extension.
Call Park To Other
Park the call on the system with parked call indication on the selected extension.

5.2.2 Unparking Calls (Status Menu)

While parked calls are parked on the telephone system and can be unparked by any other user, the parked call indication is sent to a particular extension. If there are any calls parked against your phone, you can view and unpark them via the Status menu.

Press the Status soft key if shown.

To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.

If you have any parked calls, the Parks option is displayed. The option is not present if you do not have calls parked against your extension.=
Press the Details soft key.
Use the up and down arrow keys to scroll through the parked calls.
To unpark a particular call, press the Connect soft key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

5.2.3 Park & Page

This method of parking calls is available only if specifically configured on your telephone system. To use it, you also need to add a Park & Page button on your phone. See Button Features.

Park and page use a set of park slot numbers, configured by your system administrator, that act like extension numbers. When you park a call in one of those park slots, you or any other user on the system can dial that park slot number to unpark the call.

Your system administrator can also configure up to 3 hunt groups for paging. When you park a call, after displaying the park slot number used, your phone displays options for paging.

Calls parked using Park & Page are not indicated in your phone’s Status menu. However, calls that you park will recall to your phone if left parked for too long.

If your phone has any Call Park buttons set to match the park slot numbers configured for Park & Page, those buttons can be used to park/unpark calls and indicate when a call is parked in that park slot. However, when used to park a call, the phone does not display the page options.

To Park a Call Using Park & Page

Press the Park & Page button on your phone. The call is parked and the parked slot number needed to unpark the call is displayed.
If you want to make a page announcement of the parked call, press Page. Otherwise, press Exit.
3.There are several methods by which you can select the user or hunt group that you want to page:

Select one of the pre-configured hunt groups and press Page.
Press Dir. Select the required user or hunt group from the directory and press Page.
Dial the extension number of the user or hunt group that you want to page and then press Page.

To Unpark a Call

Dial the parking slot number that was assigned to the parked call.

Chapter 6. Transferring Calls

You are able to transfer calls even if all your current call appearance buttons are in use.

Press Transfer. The current call is automatically put on hold pending transfer.
Dial the number for the transfer. Alternatively, press Dir to select a destination from the directory or use the Redial option, if applicable.

To complete the transfer, press Complete. You can do this while the call is still ringing.
Transferring a call while it is still ringing is called an unsupervised transfer.
Transferring a call after ringing finishes is called a supervised transfer.
If the transfer destination does not answer or, after answering the call, does not want to accept the call, press the Cancel soft key.

Press Complete to complete the transfer. If the transfer destination does not answer or does not want to accept the call, press the Cancel soft key.

Notes
Calls and Button Status Indication
The status indication for a call on hold pending transfer differs from that used for standard held calls:

On phones with dual lamp buttons, both the green and red lamps fast flash (flutter) when the button represents a call on hold pending transfer.
On phones with single lamp buttons or status icons, Xfer: is shown in front of the caller ID information rather than the button name. For example Xfer:Extn299 is shown rather than a = Extn299.
The call status information shown when a call on hold pending transfer is highlight is prefixed with On-Hold-Xfer rather than On-Hold.

Switching Between Calls
Switching from a connected call to an existing call on hold pending transfer puts the connected call on hold pending transfer.

6.1 Transferring to Voicemail

When set to visual voice mode, the key can be used to transfer your current call to the voicemail mailbox of another user or group.

With the call connected, press the key. You are still connected to the call and can continue talking.
Dial the extension number of the user or group to which you want to transfer the call.
When the number matches a user or group, their name is displayed.

To transfer the call to the user or group’s mailbox, press Select. The caller will hear a few seconds of ringing and then the mailbox greeting.
To exit the transfer menu, press Cancel.

6.2 Transferring a Held Call

There are various call transfer scenarios to consider:

If you have multiple calls on hold and you want to transfer a connected call to one of the held calls

Press the Transfer soft key and use the up and down arrow keys to select the desired call appearance. When you are satisfied, press Complete to transfer the call while the other held call(s) remain on hold.

If you have calls on hold but you want to connect your current call with a new destination:

Press the Transfer soft key and enter the destination manually using the numerical keypad and press Complete. Alternatively, press Dir to select a destination from the directory or use the Redial option, if applicable.

If you have a destination call connected but you wish to refer back to the originating call before completing the transfer:

Do NOT press Complete to transfer the destination call as in scenario #2. Select the originating call (‘on hold pending transfer’) by pressing its call appearance button. This will place the destination call ‘on hold pending transfer’ so that you can notify the originating caller. With the originating call connected, you can now press Complete to connect the two calls. Held calls that are not pending transfer will not be affected. Moreover, it is not possible to have more than one call ‘on hold pending transfer.’

6.3 Transferring a Call to Your Mobile

If you have been configured as a mobile twinning user, you can transfer a call to your mobile device using the features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
If necessary, use the up and down arrow keys to highlight Transfer to Mobile. Press Select. Access Control Your system administrator can configure whether you can access this menu option. See Menu Access Control.

Chapter 7. Account Codes

The telephone system can store a number of account codes. Account codes may be used to keep track of calls in relation to particular activities or clients. They can also be used to keep track of calls by particular users or sets of users.

When an account code is entered while making a call or during a call, that account code is included in the call records output by the system.
Accounts entered are checked against those stored by the telephone system. If an invalid code is entered, the account code is requested again.
The system administrator can configure certain numbers or types of numbers to require the entry of an account code before you can continue making a call to such a number.
The system administrator can also configure a requirement for you to enter an account code before making any external call.

7.1 Forced Account Code Entry

The system administrator can configure certain numbers or types of numbers to require the entry of an account code before you can continue making a call to such a number.

The Account Code menu is displayed when you are required to enter an account code.
Enter the account code that you want to use.
Press the Done soft key.
If the account code was not a valid account code, the REENTER ACCOUNT menu is displayed.

7.2 Manual Account Code Entry

You can enter account codes during a call or before making a call. The account code that you enter must match an account code set on the telephone system.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Account Code.
Press the Set soft key or the OK button or the right arrow key.
Enter the account code that you want to use.
Press the Done soft key.
If the account code was not a valid account code, the Failed menu is displayed.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control. Feature Button Access to the enter account code menu can be assigned to a feature button configured with the Account Code Entry action. The button can also be preset with a specific account code.

Chapter 8. Conference Calls

The telephone system supports multiple conference calls, with additional parties addable to any conference call until the system’s conference capacity is reached. A maximum of 64 parties in any particular conference call is supported. Conference resources are also used for call recording and other features, reducing the available conference capacity for
ordinary conference calls.

Some conference controls, for example dropping other parties, only apply to conferences started on the same phone system as your extension.

Note
If you are the only internal user in the conference, depending on your telephone system’s configuration, dropping yourself might end the conference. Consult your system administrator for details.

Default Short Codes

Conference Held Calls: *47
Start a conference between yourself and any calls that you have on hold.

8.1 Starting a Conference

If you do not already have a held call, you can use the process below to start a conference. For more complex scenarios see Context-Sensitive Conferencing.

Make a call to the first party or answer a call.
Press the Conf soft key. The current call is automatically put on hold.
Dial the party that you want to add to the conference.
If they answer and want to join the call, press Conf again.
If they do not want to join the call or do not answer, press Drop and then press the appearance key of the heldcall.

8.2 Adding a Call to a Conference

You can add parties to an existing conference.

Press HOLD to put the conference on hold. This does not affect the other conference parties who can continue
talking to each other.
Press an available appearance key on which to make a call.
Dial the party that you want to add to the conference.
If they answer and want to join the call, press Conf again.
If they do not want to join the call or do not answer, press Drop and then press the appearance key of the held call.

8.3 Viewing Conference Details

You can display a list of the parties involved in a conference call.

If not already displayed, press the up or down arrow key to display the conference call.
Press the Details soft key.

To scroll through the list of callers in the conference, use the up and down arrow keys.
To drop a caller from the conference, highlight them and press Drop.
To mute a caller, highlight them and press Mute. Repeat this to unmute them.
To return to the call display, press the Back soft key.

8.4 Dropping/Muting Parties

You can drop parties from a conference call, including yourself. You can also mute other parties.

While connected to a conference call, if you press the Details key, the conference details menu is displayed.
You can then perform the following actions:

To scroll through the list of callers in the conference, use the up and down arrow keys.
To drop a caller from the conference, highlight them and press Drop.
To mute a caller, highlight them and press Mute. Repeat this to unmute them.
To return to the call display, press the Back soft key.

8.5 Holding a Conference Call

Using the Hold soft key you can put a conference call on hold in the same way as you can for a normal call. The appearance key for the conference call will show a fast-flashing red lamp.

To take the conference call off hold, press the appearance key.

Important – Holding Conference Calls

Warning: This only applies to conference calls hosted by your own telephone system. Holding your call to a conference hosted on another telephone system may cause that conference to hear your system’s music on hold.

8.6 Context Sensitive Conferencing

The scenarios for starting a conference and adding a call to a conference cover just simple scenarios where no other calls are in progress. The phone supports a range of context-sensitive scenarios to control which calls are added to the conference

For this phone, which calls are conferenced when Conf or Conference is pressed depends on which call is currently highlighted on the phone’s display and the types of other held calls.

Changing which call is currently highlighted

On phones with a set of cursor keys, the up and down cursor keys can be used to select the current highlighted call appearance, even while there is a currently connected call. On touchscreen phones, the cursor buttons on the right-hand edge of the screen can be used for the same purpose.

On most phones in the series, the background shading indicates the currently highlighted call. The exception is 9611, 9621, and 9641 telephones where a yellow symbol is shown on the right of the currently selected cell.

Chapter 9. Headset/Handsfree Operation

9.1 Headset Operation

Your phone has a headset socket located under the phone. This is suitable for the connection of phone headsets that connect via a HIS headset cable.

If there are no currently connected calls to which you are talking, a call answered by pressing its appearance button is connected either handsfree or through the headset according to the phone’s audio path setting.
If there is already a connected call to which you are talking through the headset, answering another call by pressing the appearance button will answer that call using the headset.

Using a Headset

To answer a call using a headset:

To answer a call using the headset, press the HEADSET button. The button remains lit whilst you have a call connected on the headset.

To end a headset call:

To end a headset call, press the HEADSET button.

To switch from the headset to the handset:

To switch from the headset to the handset, simply lift the handset.

To switch to handsfree from the headset:

To switch to handsfree from the headset, press the HEADSET button. The button remains lit whilst you have a call connected on the headset.
Replace the handset.

To switch from the headset to handsfree:

Press the SPEAKER button. See Handsfree Speaker Operation.

To switch to headset from handsfree:

Press the HEADSET button. The button remains lit whilst you have a call connected handsfree.

To mute the call while on the headset:

Press the MUTE button. The button remains lit whilst the call is muted. Note that if you switch to the handset or handsfree, the mute is automatically canceled.

Headset Operation Settings

You can adjust the following headset settings:

Headset Volume
Default Audio Path
Headset Automatic Gain Control On/Off

9.1.1 Headset Volume

While talking via the headset, you can adjust the volume of the incoming call. The status indication line displays an icon followed by eight bubbles that represent the volume level.

With the call connected on the headset, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

9.1.2 Default Handsfree Audio Path

By default, when you make a call or answer a call without lifting the handset, the audio is played through the phone’s speaker while you speak via the phone’s microphone.

If you have a headset attached, you can change the phone’s behavior so that the audio is played through the headset by default rather than the speaker.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Audio Path.
Press Change to change the setting between Headset and Speaker.
When completed, press the Save soft key.
Press the Back / Exit soft keys to exit the menus.

9.1.3 Automatic Gain Control

When using automatic gain control (AGC), the phone tries to maintain a constant audio level even if the incoming call changes between loud and quiet.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Advanced Options. Press Select.
Use the up and down arrow keys to highlight Automatic Gain Control. Press Select.

Use the up and down arrow keys to switch between Handset, Headset, or Speaker settings for AGC.
To change the highlighted setting, press Change.

When completed, press Save.
Press Back / Exit to exit the menus.

9.1.4 Headset Alert Sounds

When using a headset, the phone can provide additional audio alerts through that headset, These alerts are in addition to the phone’s normal visual alerting and ringer.

The phone can provide headset alerts when it goes off and on the hook. It can also provide a headset alert when calls are waiting to be answered. That includes calls waiting to be answered when you already have a call connected.

Enabling Headset Alerts

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Select Headset Signalling.
Select the headset alerting mode required:

None
The phone does not provide any additional alert sounds through the headset.
Switchhook only
The phone provides alert sounds when the phone goes off-hook (a single click) or back on-hook (a double click).
Switchhook & Alerting
The phone provides alerts as above plus an additional alert (three clicks) whenever a call is waiting to be answered.
6. Depending on the phone, press either Save or Select.

9.2 Handsfree Speaker Operation

Your phone has a speaker and microphone that allows you to make and answer calls hands-free. The speaker is located
under the handset. The microphone is located near the bottom right of the phone’s keypad.

If there are no currently connected calls to which you are talking, a call answered by pressing its appearance button is connected either handsfree or through the headset according to the phone’s audio path setting.
If there is already a connected call to which you are talking handsfree, answering another call by pressing the appearance button answers that call handsfree.

Conference Phones

Your phone is not designed as a conference room speakerphone. It is designed for use by a speaker located directly in front of the phone with no obstructions between themselves and the microphone. Phones designed to be used as conference speakerphones typically have multiple microphones and are able to handle sounds coming from multiple directions. For details of conference speakerphones supported by your phone system contact your system administrator.

Using Handsfree

To answer a call handsfree:

To answer a call hands-free, press the SPEAKER button. The button remains lit whilst you have a call connected handsfree.

To end a handsfree call:

To end a hands-free call, press the SPEAKER button.

To switch from handsfree to the handset:

To switch from handsfree to the handset, simply lift the handset.

To switch to handsfree from the handset:

To switch to handsfree from the handset, press the SPEAKER button. The button remains lit whilst you have a call connected handsfree.
Replace the handset.

To switch from handsfree to the headset:

Press the HEADSET button. See Headset Operation.

To switch to handsfree from the headset:

Press the SPEAKER button. The button remains lit whilst you have a call connected handsfree.

To mute the call while handsfree:

Press the MUTE button. The button remains lit whilst the call is muted. Note that if you switch to the handset or headset, the mute is automatically canceled.

Handsfree Operation Settings

You can adjust the following handsfree settings:

Speaker Volume
Default Audio Path
Speaker Automatic Gain Control On/Off

9.2.1 Speaker Volume

While talking hands-free via the phone’s speaker, you can adjust the volume of the incoming call. The status indication line will display an icon followed by eight bubbles that represent the volume level.

With the call connected to the speaker, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

9.2.2 Default Handsfree Audio Path

By default, when you make a call or answer a call without lifting the handset, the audio is played through the phone’s speaker while you speak via the phone’s microphone.

If you have a headset attached, you can change the phone’s behavior so that the audio is played through the headset by default rather than the speaker.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Audio Path.
Press Change to change the setting between Headset and Speaker.
When completed, press the Save soft key.
Press the Back / Exit soft keys to exit the menus.

9.2.3 Automatic Gain Control

When using automatic gain control (AGC), the phone tries to maintain a constant audio level even if the incoming call
changes between loud and quiet.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Advanced Options. Press Select.
Use the up and down arrow keys to highlight Automatic Gain Control. Press Select.

Use the up and down arrow keys to switch between Handset, Headset, or Speaker settings for AGC.
To change the highlighted setting, press Change.

When completed, press Save.
Press Back / Exit to exit the menus.

Chapter 10. Contacts/Directory

This menu is accessed by pressing the CONTACTS key. It is used to display names and numbers that you can then use for making calls.

The directory includes names stored for use by all users, names stored for use by just you, and the name and numbers of
all the other users and groups on the phone system.

The contacts are shown in the directory come from a number of sources.

Personal Directory Contacts
These contacts are stored by the telephone system as part of your user settings.

They are displayed on the phone while you are using it. If you hot desk to another phone that also stores your contacts on the system, your personal contacts move with you.
You can have up to 100 personal directory entries that you can add, edit and delete through the phone. Note: While each user is allowed up to 100 personal directory entries, the total capacity of the system may limit the addition of further personal directory entries for all users.
The system administrator can add, edit and delete your personal directory entries.
The system administrator can also set users and hunt groups as Ex Directory. Those users and hunt groups are then not included in the directory.

User Contacts
These contacts list all the other users on the telephone system. If your system is part of a Small Community Network of IP Office telephone systems, it includes users on the other systems.

Group Contacts
These contacts list all the hunt groups on the telephone system. If your system is part of a Small Community Network of IP Office telephone systems, it includes those hunt groups that the system administrator has configured to be advertised across the network.

External Contacts
These contacts are viewable and useable by all phone users. These are two types of external contacts:

Some external contacts are entered into the telephone system configuration by the system administrator.
Other external contacts are those imported by the telephone system from other directory sources. Note: If you have been configured as a system phone user by the system administrator, then you can also add, edit and delete some external directory contacts.

10.1 Managing External Contacts

If you have been configured as a system phone user by the system administrator, then you can also add, edit and delete some external directory contacts.

This only applies to external directory contacts entered locally into the configuration of the telephone system to which you are logged in.
External directory contacts imported by the system from other sources cannot be edited. However, if a local entry is created with the same name or number as an imported entry, the imported entry is discarded in favor of the local one.

10.2 Viewing Contacts Details

Access the contacts directory:
a. Press the CONTACTS key. The directory menu is displayed.
b. Use the left and right arrow keys to select which type of directory entries you want to display.

All
All directory entries.
External
Directory entries are stored by the telephone system for all users to use.
Groups
The names and numbers of hunt groups on the telephone system
Users
The names and numbers of other users on the telephone system.
Personal
Your own personal directory entries.

d.To view more details of the highlighted name, press Details. To return to the directory press List.

2. When the required entry is highlighted, press Details to display the name, number, and type of contact.

Use the up and down arrow key to scroll through the contacts.
The range of soft keys available will depend on the type of directory entry:

Call
Make a call to the stored number.
List
Return to the list of contacts
More
If the contact is one of your personal directory entries, the More soft key will be present to allow you to access the options below. It is also present for external directory entries if you have been set as a system
phone user by the system administrator.
Edit
Edit the name and number.
Delete
Delete the name and number.
New
Add a new personal directory contact.

10.3 Making a Call from the Directory

You can use any directory contact to make a call. You can also use the directory in almost any telephone function where you need to select the number for a destination, for example during a transfer.

Access the contacts directory:

a. Press the CONTACTS key. The directory menu is displayed.

b. Use the left and right arrow keys to select which type of directory entries you want to display.

All
All directory entries.
External
Directory entries are stored by the telephone system for all users to use.
Groups
The names and numbers of hunt groups on the telephone system.
Users
The names and numbers of other users on the telephone system.
Personal
Your own personal directory entries.
c. Use the up and down arrow keys to scroll through the list or start dialing the name you want to find to display only matching entries. If you dial a name to return to the full list press the Clear soft key.

d. To view more details of the highlighted name, press Details. To return to the directory press List.

When the required entry is highlighted, press Call or press the button next to the name.
Proceed as you would with a normally dialed call.

10.4 Using the Directory for Other Functions

Within other menus where entry of a number is required, it may be possible to use the directory to select an existing number by name. If this option is available, it will be indicated by the presence of a Dir soft key in the menu.

When using the directory in this way, the names made available will depend on the type of function that is being set. For example, for some functions, only group names will be displayed, for others only user names.

Press the Dir soft key.
Either dial the name to see a list of matches or press the List soft key to list all names.

a. Use the up and down arrow keys to scroll through the list or start dialing the name you want to find to display only matching entries. If you dial a name to return to the full list press the Clear soft key.

b. To view more details of the highlighted name press Details. To return to the directory press List.

When the required entry is highlighted, press Select.
You will be returned to the menu in which you selected the Dir soft key.

10.5 Adding a New Contact

So long as the telephone system capacity has not been reached, you can add up to 100 personal directory entries.

Access your personal directory contacts:

a. Press the CONTACTS key. The directory menu is displayed.

b. Use the left and right arrow keys to select your Personal directory.

Press the New soft key.

The menu now allows editing of the name and number.
Use the up and down arrow keys to switch between number and name entry.
When the name and number have been entered as required, press the Save soft key.
To exit without making any changes, press the Cancel soft key.

Note
If you have been configured as a system phone user by the system administrator, then you can also add, edit and delete some external directory contacts.

10.6 Adding a Contact from the Call Log/History

You can add a name and number shown in your call log to your personal contacts.

Access the call log.
a. Press the HISTORY button.

b. The display will change to show your call log records. The caller’s name is shown if known, otherwise the number. If you have any new missed call records, the button is illuminated and the call log will open showing your missed calls.

d. Use the up and down arrow keys to scroll through the records.

Press More and then press the +Contact soft key.
Use the up and down arrow keys to switch between the name and number details for the new contact.
Using the telephone keypad and the Bksp soft key you can edit the name and the number. When editing the number, use the Pause soft key to enter a comma (,) for a 1 second pause in the number dialing.
When the name and number are set as required, press the Save soft key. To return without saving the name and number, press the Cancel soft key.

10.7 Editing a Contact

You can edit the contacts in your own personal directory.

Access your personal directory contacts:
a. Press the CONTACTS key. The directory menu is displayed.

b. Use the left and right arrow keys to select your Personal directory.

d. To view more details of the highlighted name, press Details. To return to the directory press List. 2.Locate the required entry.

Press the Details soft key.
Press the More soft key and then the Edit soft key.

The menu now allows editing of the name and number.
Use the up and down arrow keys to switch between number and name entry.
When the name and number have been entered as required, press the Save soft key.
To exit without making any changes, press the Cancel soft key.

Note
If you have been configured as a system phone user by the system administrator, then you can also add, edit and delete some external directory contacts.

10.8 Deleting a Contact

You can delete a contact from your own personal directory.

Access your personal directory contacts:
a. Press the CONTACTS key. The directory menu is displayed.

b. Use the left and right arrow keys to select your Personal directory.

d. To view more details of the highlighted name, press Details. To return to the directory press List. 2. Locate the required entry.

Press the Details soft key.
Press the More soft key and then the Delete soft key.
Press the Delete soft key again to confirm the action.

Note
If you have been configured as a system phone user by the system administrator, then you can also add, edit and delete some external directory contacts.

Chapter 11.
Call History

This menu is accessed by pressing the HISTORY key. The call log you see is a call log stored on the telephone system. If you log in at another phone that also stores a call log, your call history moves with you.

Your call history contains your most recent answered calls, the most recent calls you made and the most recent missed calls. If configured by the system administrator, it can also include the most recent calls missed by each hunt group of which you are a member.

Making a Call
Viewing Call Details
Deleting a Record
Deleting All Records
Add a Record to Your Contacts

Missed Calls

Missed calls are calls to you that you did not answer. Your system administrator can also configure whether or not the log includes calls presented to you but are answered by someone else or by voicemail.

The History button is illuminated when you have any new missed calls in your call log. The lamp is extinguished when you have viewed the missed call in the call log or the record of that call is no longer in your call log.

The icon is also used at the top left of the phone display to indicate missed calls and is prefixed with the number of missed calls.

Missed Group Call

If you are a member of any hunt groups, the system administrator can configure whether your missed calls log should also include missed hunt groups calls. The hunt group does not necessarily have to have rung at your phone. It will be recorded as missed if it was presented to the hunt group and not answered by any of the members including you.

Notes
A centralized call log can be turned off by the system administrator. In that case, the call log is stored by the phone and is lost if the phone is reset. This guide only covers the centralized call log stored by the telephone system.
The call log on other types of phones is a local call log maintained by that phone. It will not move with you when you hot desk and it will be lost if the phone is restarted.
The redial function uses the outgoing call records stored in the call log.

11.1 Accessing the Call Log/History

Access the call log.
a. Press the HISTORY button.

d. Use the up and down arrow keys to scroll through the records.

Pressing OK will make a call to the number stored with the currently displayed record.
You can use the functions listed at the bottom of the display by pressing the soft key below the function name.

Call
Make a call to the number stored in the currently displayed call log record.
Details
Display more details about the current call log record. You can also add the caller details to your personal directory if required.
Delete
Deletes the currently displayed record.
More
Switch between the different sets of available soft key functions.
Del All
Delete all the call log records, not just the current types of records being shown.
+Contact
Add the currently highlighted call log record to your personal contacts.

To exit the call log, press the PHONE/EXIT button.

11.2 Making a Call

You can use the call log to make calls to the number included in the currently selected call record.

Access the call log.
a. Press the HISTORY button.

b.The display will change to show your call log records. The caller’s name is shown if known, otherwise the number. If you have any new missed call records, the button is illuminated and the call log will open showing your missed calls.

d. Use the up and down arrow keys to scroll through the records.

Press Call to call the number displayed in the call record.

11.3 Viewing Call Details

You can view additional details about the currently shown call.

Access the call log.
a. Press the HISTORY button.

d. Use the up and down arrow keys to scroll through the records.

Press the Details soft key. The individual details of the currently selected call record are displayed. The possible values are:

Name – The name of the caller if known.
Number – The number of the caller if available.
Time and Date – The time of the call.
Call Type Icon – The type of call record, ie. = Incoming, = Outgoing or = Missed.
Count – How many time a call of the same type, name and number has occurred. Only the details of the most recent call are kept in your call log. However the count will indicate if the caller has rung or has been rung several times.
Duration – The length of the call.

While you are in the details of a call record, the soft key functions available are:

Call
Call the number shown in the call record. You can also do this by pressing the OK button.
List
Go back to the normal call screen to select another call record. You can also use the up and down arrow keys to view the previous or next record.
Delete
Delete the currently displayed record.
More
Switch between the different sets of available soft key functions.
+Contact
Add the name and number to your personal directory. You can edit the details before they are added.
Delete All
Delete all the records.

11.4 Deleting a Record

You can delete the currently displayed call record. If the record is a missed hunt group call, the record is also deleted from the call log of other users configured to see the same hunt group’s missed calls.

Access the call log.
a. Press the HISTORY button.

d. Use the up and down arrow keys to scroll through the records.

When the required record is highlight, press More and then press

Delete. 11.5 Deleting All Records

You can delete all call records from your call log. This action deletes all call log record types (Incoming, Missed, and Outgoing), not just the type you are currently viewing. This action deletes your personal call records and any hunt group call records.

Access the call log.
a. Press the HISTORY button.

d. Use the up and down arrow keys to scroll through the records.

Press the More soft key.
Press the Del All soft key to delete all your call log records.

11.6 Adding a Record to Your Contacts

You can add a name and number shown in your call log to your personal contacts.

Access the call log.
a. Press the HISTORY button.

d. Use the up and down arrow keys to scroll through the records.

Press More and then press the +Contact soft key.
Use the up and down arrow keys to switch between the name and number details for the new contact.
Using the telephone keypad and the Bksp soft key you can edit the name and the number. When editing the number, use the Pause soft key to enter a comma (,) for a 1 second pause in the number dialing.
When the name and number are set as required, press the Save soft key. To return without saving the name and number, press the Cancel soft key.

Chapter 12. Voicemail

If your telephone system includes a voicemail server, pressing the MESSAGES button accesses voicemail. Your system administrator can configure whether the access uses either spoken prompts from the voicemail server or visual menus on the phone called ‘visual voice’. This guide assumes the default operation of using the visual voice menus.

Using visual voice, you can access the following functions:

Checking Messages
Record and Send a Message
Change Your Mailbox Greeting
Change Your Mailbox Name
Select a Voicemail Email Mode
Change Your Voicemail Code
Turn Use of Voicemail On/Off
Transfer to Voicemail
Send a Call to Voicemail

Other Functions

This guide covers just the visual voice functions that you can use from the phone’s menus. For the full range of mailbox controls that you may be able to use, contact your system administrator for the IP Office mailbox user guide appropriate to the type of voicemail server and mailbox mode that your system uses.

Default Short Codes

Check Messages: *17
Access mailboxes to check for messages.
Voicemail On: *18
Allow voicemail to be used to answer calls.
Voicemail Off: *19
Stop voicemail being used to answer calls.
Voicemail Ringback On: *48
Have voicemail ring your phone when you have any new messages. It will call when you use the phone.
Voicemail Ringback Off: *49
Switch off ringback.

12.1 Message Waiting Indication

Both the MESSAGES button and the message lamp on your phone are used to indicate when you have new messages in your voicemail mailbox. They remain lit until you have played each of the new messages.

The system administrator can also configure it so that you receive new messages waiting for indications for hunt groups.

12.2 Visual Voice

This menu option provides an alternate route into visual voice if the MESSAGES key has not been set up to do that.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Visual Voice. Press Select. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

12.3 Checking Messages

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press Done.
The Visual Voice menu is displayed. The numbers shown against the Listen option indicate the number of new, old, and saved messages in your mailbox. If the system administrator has configured you to receive message waiting indication for any hunt group mailboxes, you can also use the up and down arrow keys to highlight hunt group names and the number of messages in those mailboxes.
Highlight Listen and press Select.
Use the up and down arrow keys to highlight which messages (New, Old or Saved) that you want to listen to and press Select. The details of the first message of that type are displayed.
You can use the up and down arrow keys to scroll through the messages.
Use the soft keys to control the playback actions for the currently highlighted message:

Play / Pause
Start/stop playback of the currently displayed message.
Call
Call the person who left the message.
Back
Return to the previous menu.
More
Switch between the different sets of available soft key functions.
Delete
Delete the message.
Save
Mark the message as saved. Saved messages are not normally automatically deleted.
Copy
Copy the message to another mailbox. The menu will prompt you to enter the destination number.

Automatic Message Deletion

By default, messages are automatically deleted a set time after being played. The delay depends on the particular voicemail server (24 hours for embedded voicemail, 30 days for Voicemail Pro). For voicemail messages on a Voicemail Pro system, the system administrator can customize the delay and can also apply automatic deletion times to new and saved messages.

12.4 Sending a Message

You can use visual voice to record and send a voicemail message to other users’ mailboxes.

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to scroll to the option Message and press Select.
Press Record to start recording a message.
To stop recording, press Stop. 6.You can now use the following soft keys:

New
Record the message again.
Send To
Enter the number to which you want to send the message and press Add. You can add several numbers. When the list of numbers to which the message should be sent is complete press Send.
Play
Listen to the recording.
Cancel
Abandon the message.

12.5 Email Mode

Voicemail email is a feature where emails are sent to your email address when your voicemail mailbox receives a new voicemail message. The email can include the voicemail message as an attachment or it can be just an alert. Through the Visual Voice menu you can change the mode of voicemail email operation.

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to scroll to the option Email. This option is only available if your email address has been set in your voicemail settings by the system administrator.
The menu displays your current voicemail email mode setting. Press Change to scroll through the possible settings:

Off
Do not send any emails.
Copy
Send an email with a copy of the new voicemail message attached.
Forward
Send an email with the new voicemail message attached and delete the message from the voicemail mailbox.
Alert
end an email telling you there is a new message but do not attach a copy of the message.

When the required setting is displayed, press Save. To exit without changing the setting, press Cancel. Access Control Your system administrator can configure whether you can access this menu option.

12.6 Mailbox Greeting

While the voicemail system will play a generic greeting to a caller, prompting them to leave a message, you can record your own greeting.

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to scroll to the Greeting option and press Select.
Use the soft keys to listen to and record your mailbox greeting.

Record
Record a new greeting. Note that the greeting must be at least three seconds long or the voicemail system will discard it.
Listen
Listen to the current greeting or the new greeting just recorded.
Submit
Submit the new recording as your mailbox greeting.
More
Switch between the different sets of available soft key functions.
Delete
Delete your current mailbox greeting. The greeting will return to its default mailbox greeting.
Cancel
Return to the main Visual Voice menu.

12.7 Mailbox Name

Use the following procedure to record a mailbox name. This feature is only available on systems using Embedded Voicemail.

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to scroll to the Name option and press Select.
Use the soft keys to listen to and record your mailbox name.

Record
Record a new name.
Listen
Listen to the current name or the name just recorded.
Submit
Submit the new recording as your mailbox name
More
Switch between the different sets of available soft key functions.
Delete
Delete your current mailbox name. The voicemail will use the default name.
Cancel
Return to the main Visual Voice menu.

12.8 Changing Your Voicemail Code

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to scroll to the Password option and press Select.
Enter your current password and press Save.
Enter the new password that you want to use. The new password must be at least four digits long. A series of numbers (for example 1234) or repeated numbers are not allowed.
When the desired password is complete, press Save.

12.9 Switching Voicemail On/Off

You can control whether the telephone system uses voicemail to answer your unanswered calls. This does not switch off your mailbox which you can still access to play existing messages and use other functions.

Press the MESSAGES button. Depending on how your system is configured, you may be required to enter your voicemail password and then press the Done soft key.
The Visual Voice menu is displayed.
Use the up and down arrow keys to highlight Voicemail.
Press the Change to switch between On or Off.
Press Save to save the change.

12.10 Transferring to Voicemail

When set to visual voice mode, the key can be used to transfer your current call to the voicemail mailbox of another user or group.

With the call connected, press the key. You are still connected to the call and can continue talking.
Dial the extension number of the user or group to which you want to transfer the call.
When the number matches a user or group, their name is displayed.

To transfer the call to the user or group’s mailbox, press Select. The caller will hear a few seconds of ringing and then the mailbox greeting.
To exit the transfer menu, press Cancel.

12.11 Sending a Call to Voicemail

You can transfer a call targeted at you directly to your voicemail mailbox.

If the call is not the currently highlighted call on the display, use the up and down arrow keys to highlight it.
Press the To VM soft key. The call is redirected to your mailbox.

Chapter 13. Logging In/Out

You may always use the same phone in the same location. However, the telephone system provides a number of features
that allow you to use any phone on the system to make and receive calls.

Log In
You can log in at any phone that you want to use. All your calls are then redirected to that phone and your user settings are applied to calls made and received. If it is a phone that stores your contacts and call history on the system, your contacts and call log are displayed by the phone.
Any other existing user of that phone is logged out while you are logged in.
If you were logged in on another phone, you are logged out from it.
If your phone system is in a Small Community Network (SCN) of phone systems, it may be possible to log in at extensions located on other phone systems in the network. Your system administrator will advise you if you can ‘remote hot desk’ and what features will still be available to you when you do.
Log Out
When you log out from a phone, or are logged out by another user logging in, the telephone system may apply several actions:
If you have a normal default extension and no one else is logged in there, you return to being logged in on that phone.
If you remain logged out, you are treated the same as being on ‘do not disturb’ except that all calls to you go to voicemail instead, if available.
If you have a mobile twinned number, the system administrator can configure the system so that calls are still presented to your mobile twin while you are logged out.
Lock/Unlock
Separately from logging in and out, you can lock your phone settings. While locked, the phone can still be used to answer your calls and can be used to make internal and emergency calls. However it cannot be used to make external calls and your user settings cannot be accessed through the phones menus.
You can set your phone to automatically lock itself after a period of inactivity.
Default Extension
Each extension can be configured with a default user. If you are logged off from an extension, the system will automatically log you in at your default extension if it is not in use by another user.
Login Idle Period
Your system administrator can configure a timeout which will automatically log you out if you do not use the phone in that time to make or answer a call.

Default Short Codes

Short codes are numbers that you can dial to enable and disable various features. The following are default short codes that may be available. However, your system administrator can remove and change the short codes available to you or all users.

Log In: 35N*P#
Log in to a phone using your extension number (N) and login code (P).
Log Out: *36
Log yourself out from the phone where you are currently logged in.

13.1 Logging In

When you log in to a phone, you take control of that phone. Incoming calls for you are redirected to that phone and your user information and settings are available. Any existing user on the phone is logged off when you log in.

The method for logging in depends on the current state of the phone:

Phone In Use
If the phone is already in use you can still login. The existing user will be logged out.
Logged Out
If the phone has no current user, the basic menu with just the login option is displayed.
Unregistered Phone
If the phone is not registered with the phone system, the Enter Extension menu is displayed

13.1.1 Logging In on a Phone Already in Use

You can log in to a phone that is already in use by another user. The existing user is logged out.

If the phone is already in use:

Press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Login…. Press Select.

The login menu is displayed.
Enter your extension number and press Next.
Enter your security PIN (login code).
Press Done. Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

13.1.2 Logging In on an Unregistered Phone

This method is used to log in at an unregistered phone. You can recognize an unregistered phone by entering Extension on the display. This method is not supported for hot-desking on the system; you can only log in using the base extension number originally used to install the phone.

Enter your extension number. As you enter it, you can use the Bksp and Clear soft keys to make corrections.
When your number is displayed, press the OK soft key.
Enter the phone password. Use the Bksp and Clear soft keys to make corrections. Note: This password is determined by your system administrator and is required for registration.
When you have entered the phone password, press Done. If the details are correct, you user details will be loaded into the phone.

13.1.3 Logging In on a Not Logged In Phone

This method is used to login at an extension where the previous user has logged out and the phone has no current user. You can recognize a phone in this state by NOT LOGGED IN on the display.

Press Select.
The login menu is displayed.
.Enter your extension number and press Next.
Enter your security PIN (login code).
Press Done.

13.2 Logging Out

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Logout. Press Select.
You will be logged out of the phone. The follow action will depend on several factors:

If the phone does not have a default user, or the default user is currently logged on elsewhere, the ‘no user’ display is shown:
If the phone has a default user and they are not current logged on elsewhere, they are automatically logged back in.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

13.3 Locking the Phone

Rather than logging out, you can lock your phone. You can either lock your phone manually using the steps below or have it automatically locked after a period of phone inactivity. To use the lock feature you need to set a security PIN. When your phone is locked:

It can only be used to make internal and emergency calls.
None of the menus for your user settings can be accessed.
Unlocking the phone requires your login code if you have configured a login code.

To lock your phone manually:

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Lock. Press the Select.
The phone is now locked as indicated by the display.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control .

13.4 Auto-Lock

Rather than logging out, you can lock your phone. You can either lock your phone manually using the steps below or have it automatically locked after a period of phone inactivity. To use this feature you need a security PIN (login code) set.

When your phone is locked:

It can only be used to make internal and emergency calls.
None of the menus for your user settings can be accessed.
Unlocking the phone requires your login code, if you have configured a login code.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Phone Screen Settings. Press Select.
Use the up and down arrow keys to highlight Auto Lock (minutes).
Press the Change soft key to change the setting or use the left or right arrow keys.

Disabled
Do not use the inactivity timer.
1 / 5 / 30 / 60
Lock the phone after the indicated number of minutes.

Press the Save soft key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

13.5 Unlocking the Phone

The message PHONE LOCKED indicates that the phone has been locked. While locked, the phone can only be used to make internal calls to other extensions and none of the phone and user menus can be accessed.

Press the Unlock soft key.
Enter your security PIN (login code).
Press the Done soft key.

13.6 Changing Your Security PIN

You can change your own security PIN (login code). If set, this PIN is used for logging in at other phones, locking your phone, and accessing system administration features. This is not your voicemail code used for voicemail
access.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Set Security PIN. Press Select.
Enter your current security PIN if you already have one and press Done.
Enter your new password.
Press Save.
The ‘Security PIN changed’ message will appear for a few moments.

Chapter 14. Redirecting Calls

This section looks at the different ways that you can redirect your calls to another phone.

Follow Me
Temporarily redirect all your calls to another phone that you will be sharing with that phone’s normal user. This function can be used in two ways:
Follow Me To
Set the follow me destination from your own phone.
Follow Me Here
Set the follow me destination from the phone that you want to use.
Forward
Forward calls to an internal or external number.
Forward on Busy
Forward calls when you have reached the limit of the number of calls that the phone can present to you.
Forward on No Answer
Forward calls if they have rung unanswered at your phone.
Forward Unconditional
Immediately forward calls. Forwarding to voicemail can be selected as an option.
Do Not Disturb
Redirect all calls to voicemail, if available. Otherwise, calls are redirected to a busy tone.
Do not disturb exception numbers can be used to allow calls from specific numbers to ignore do not disturb.
Twinning
Twinning is a process whereby you can have your calls ring at two different phones. You can answer calls at either phone. There are two variants of twinning, internal twinning which uses two internal extensions and mobile twinning which twins your internal extension with an external number.

14.1 Follow Me

Follow me to’ is used to redirect your calls to another extension where you will be working. The calls are presented with your user name so that they can be distinguished from calls for the extensions normal user. This allows you to share another person’s phone without logging them off their phone.

All calls are redirected and the calls are still subject to all your user settings as if they were ringing at your phone.

Follow Me To

‘Follow me to’ is the function used to enable ‘follow me’ from your own phone.

Follow Me Here

‘Follow me here’ is the function used to enable ‘follow me’ at the extension to which you want your calls redirected.

Default Short Codes

Short codes are numbers that you can dial to enable and disable various features. The following are default short codes that may be available. However, your system administrator can remove and change the short codes available to you or all users.

Follow Me Here: 12N#
Dialed at the extension to which you want your calls redirected. Use your own extension number (N) when dialing the short code.
Follow Me Here Cancel: 13N#
Dialed at the extension from which you had redirected calls. Use your own extension number (N) when dialing the short code.
Follow Me To: 14N#
Dialed at your phone. Dial the extension number (N) to which you want your calls redirected. You can dial just *14# to cancel follow me.
Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).

14.1.1 Follow Me To (Features Menu)

Using the user menu you can set and clear follow me to settings.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Follow Me To. Press Select.
Dial the number of another user. When it matches a user, their name is displayed. Alternatively, use the Dir soft key to select a user from the directory.

Save
Save the selected number as your ‘follow me to’ destination. All calls to your extension number will be redirected to that destination.
Clear
Clear the currently selected or set number.
Back
Go back to the previous menu.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

14.1.2 Follow Me (Status Menu)

If you have set a ‘follow me to’ destination for calls to your phone, you can clear or change the setting through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Follow Me To.

To clear the ‘follow me to’ setting, press the Clear soft key.
To change the destination of the setting, press the Details soft key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control. 14.1.3 Follow Me Here (Features Menu)

You may be able to change ‘follow me here’ using the Features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Follow Me Here. Press Select.

Use the menu to add or remove users.
Use the up and down arrow keys to scroll through the names.
To remove a user, press the Clear soft key.
To add a user, press the Add soft key.
Dial the number of another user. When it matches a user, their name is displayed. Alternatively, use the Dir soft key to select a user from the directory.
Press the Save soft key to set the ‘follow me here.’

14.2 Forwarding Calls

Forwarding is used to redirect calls to another extension or an external number.

Forward Unconditional
Forward unconditional can be used to immediately redirect your calls.

By default this function is only applied to incoming external calls made to you. However, if required, internal calls and or hunt group calls can also be selected.
When enabled, all calls matching the settings are forwarded to the number set as the ‘forward unconditional’ destination. That number can be internal or external.
You can still use the phone to make outgoing calls. When you go off-hook you will hear broken dial tone.
The ‘forward on busy’ and ‘forward on no answer’ options use the same forwarding destination number. If no number is set, they use the same destination as set for ‘forward unconditional.’
If you have voicemail enabled , the telephone system will attempt to redirect forwarded calls to voicemail if they are still unanswered after having rung for your ‘no answer’ time (default 15 seconds). This is not always possible for calls that have been forwarded to an external number.
D = Diverting (Forwarding) Calls
A D is shown after your extension name on the phone’s idle display when you have ‘forward unconditional’ enabled.

Forward on Busy

‘Forward on busy’ redirects your calls when your phone is not able to present you with any more alerting calls.

By default, this function is only applied to incoming external calls made to you. However, if required, internal calls can also be selected.
When enabled, all calls matching the settings are forwarded to the number set as the ‘forward on busy’/’no answer’ destination. That number can be internal or external.
‘Busy’ is defined has having no available call appearance buttons on which further calls can be presented.
Hunt group calls are not presented when you are busy and so are not forwarded by this setting.
The ‘forward on busy’ and ‘forward on no answer’ options use the same forwarding destination number. If no number is set, they use the same destination as set for ‘forward unconditional.’
If you have voicemail enabled , the telephone system will attempt to redirect forwarded calls to voicemail if they are still unanswered after having rung for your ‘no answer’ time (default 15 seconds). This is not always possible for calls that have been forwarded to an external number.

Forward on No Answer

Forward on no answer redirects calls that have alerted your phone but have not been answered.

By default, this function is only applied to incoming external calls to you. However, if required, internal calls can also be selected.
When enabled, all calls matching the settings are forwarded to the number set as the ‘forward on busy’/’no answer’ destination. That number can be internal or external.
No answer is defined as having been presented to your phone for your ‘no answer’ time (default 15 seconds).
Hunt group calls are not forwarded.
The ‘forward on busy’ and ‘forward on no answer’ options use the same forwarding destination number. If no number is set, they use the same destination as set for ‘forward unconditional.’
If you have voicemail enabled, the telephone system will attempt to redirect forwarded calls to voicemail if they are still unanswered after having rung for your ‘no answer’ time (default 15 seconds). This is not always possible for calls that have been forwarded to an external number.

Default Short Codes

Short codes are numbers that you can dial to enable and disable various features. The following are default short codes that may be available. However, your system administrator can remove and change the short codes available to you or all users.

Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).
Set the Forward Unconditional Destination: *07*N#
Set the destination number (N) for ‘forward unconditional’ when it is switched on.
Switch Forward Unconditional On: *01
Switch on ‘forward unconditional.’ A destination must have been set.
Switch Forward Unconditional Off: *02
Include Hunt Group Calls in Forward Unconditional: *50
Exclude Hunt Group Calls from Forward Unconditional: *51
Set the Forward On Busy/No Answer Destination: *57*N#
Set the destination number (N) for ‘forward on busy’ and ‘forward on no answer.’ If no number has been set, those functions will use the ‘forward unconditional’ number if set.
Switch Forward On Busy On: *03
Switch Forward On Busy Off: *04
Switch Forward on No Answer On: *05
Switch Forward on No Answer Off: *06

14.2.1 Forward Unconditional (Status Menu)

You can clear or change your ‘forward unconditional settings through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd Union

.To switch off ‘forward unconditional,’ press the Off soft key.
To change the forwarding settings, press the Details soft key.
Use the up and down arrow keys to scroll through the editing options.
Use the left and right arrow keys to switch the forwarding on or off.
Use the left and right arrow keys to select which calls should be forwarded. The options are External Only, External and Group, Non Group Calls, and All Calls.
Select edit to change the number to which calls are forwarded.

14.2.2 Forward Unconditional (Features Menu)

You may be able to change your ‘forward unconditional’ settings using the Features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Forward Unconditional. Press Select.
The screen will display your current ‘forward unconditional’ settings.

To Switch Forward Unconditional On/Off
Highlight Fwd Unconditional. Press On or Off to change the current setting. If no destination is currently set when you switch ‘forward unconditional’ on, the display will jump to the destination field.
To Select Which Calls as Forwarded
Highlight Call Type. Press Change to see the different options. When the required option is displayed press Save. The options are External Only, External and Group, Non-Group Calls and All Calls.
To Set the Forward Destination
Highlight Destination. Either press Edit and enter the number required or press To VM for the ‘forward to voicemail’ option.
If you select Voicemail as the destination, you will need to switch ‘forward unconditional’ off in order to cancel it and enter a new destination.

14.2.3 Forward On Busy/No Answer (Features Menu)

You may be able to use the Features menu to switch ‘forward on no answer’ and ‘forward on busy’ on or off.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Fwd Busy/No Answer. Press Select.

Use the up and down arrow keys to scroll through the menu options.
To switch ‘forward on busy’ on or off, highlight Fwd Busy and press On or Off.
To switch ‘forward on no answer’ on or off, highlight Fwd No Answer and press On or Off.
To select which calls are forwarded highlight Call Type. Press Change to change the option between All Calls or External Calls Only.
To change the destination highlight Destination and press Edit. Enter the number and press Select.
Press Save to save any changes.

14.2.4 Forward On No Answer (Status Menu)

If your phone is set to ‘forward on no answer ‘ you can clear or change the forward settings through the Status menu.

Press the Status soft key if shown. · To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd No Answer.
To switch the forward off press Off.
To change the forward setting press Details.

Use the up and down arrow keys to scroll through the menu options.
To switch ‘forward on busy’ on or off, highlight Fwd Busy and press On or Off.
To switch ‘forward on no answer’ on or off, highlight Fwd No Answer and press On or Off.
To select which calls are forwarded highlight Call Type. Press Change to change the option between All Calls or External Calls Only.
To change the destination highlight Destination and press Edit. Enter the number and press Select.
Press Save to save any changes.

14.2.5 Forward On Busy (Status Menu)

If your phone is set to ‘forward on busy,’ you can clear or change the forward settings through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd Busy.
To switch the forward off press Off.
To change the forward setting press Details.

Use the up and down arrow keys to scroll through the menu options.
To switch ‘forward on busy’ on or off, highlight Fwd Busy and press On or Off.
To switch ‘forward on no answer’ on or off, highlight Fwd No Answer and press On or Off.
To select which calls are forwarded highlight Call Type. Press Change to change the option between All Calls or External Calls Only.
To change the destination highlight Destination and press Edit. Enter the number and press Select.
Press Save to save any changes.

14.3 Do Not Disturb

When you are in ‘do not disturb,’ your callers are redirected to voicemail if available. Otherwise, you hear a busy tone.

The only people who can call you are those calling from numbers in your ‘do not disturb’ exceptions list. Forwarding can still be applied to these calls.
Calls to any hunt group of which you are a member are not presented to you (unless you are the last available member of the group).
Enabling ‘do not disturb’ will not affect any calls already being presented to your phone.
You can still use the phone to make outgoing calls. When you go off-hook you will hear broken dial tone.
N = No Calls (Do Not Disturb)
An N is shown after your extension name on the phone’s idle display when you have ‘do not disturb’ enabled

Default Short Codes

Short codes are numbers that you can dial to enable and disable various features. The following are default short codes that may be available. However, your system administrator can remove and change the short codes available to you or all users.

Switch Do Not Disturb On: *08
Set your phone to ‘do not disturb.’
Switch Do Not Disturb Off: *09
Switch off ‘do not disturb.’
Add a Do Not Disturb Exception Number: 10N#
Add a number (N) to your list of ‘do not disturb’ exceptions.
Delete a Do Not Disturb Exception Number: 11N#
Remove a number (N) from your list of ‘do not disturb’ exceptions.
Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).

14.3.1 DND On/Off (Features Menu)

You can use the Features menu to switch ‘do not disturb’ (DND) on or off. Enabling DND will not affect any calls already being presented to your phone. Hunt group calls will also still be presented if you are the only available member of the group.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Press Change to change the setting.
Press Save to save the setting.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

14.3.2 DND Off (Status Menu)

You can use the Status menu to switch off ‘do not disturb.’

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If necessary use the up and down arrow keys to highlight Do Not Disturb. To clear the ‘do not disturb’ setting, press the Off soft key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

14.3.3 Do Not Disturb Exceptions

These numbers are used to indicate callers who you want to be allowed to call you as normal even when you have ‘do not
disturb’ on. This does not include group calls that are not presented when you are in ‘do not disturb’.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight DND Exceptions. Press Select.
To add a number, highlight Add Another. Dial the number and press Add.
To remove an existing number, highlight it and press Remove.
Press Done when completed.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

14.4 Twinning

Twinning is a process whereby your calls ring on two phones. Twinning is only available if configured by your system administrator.

The system supports two twinning methods: internal twinning and mobile twinning.

Internal Twinning

This method of twinning twins your normal phone with another internal phone. Your incoming calls will ring on both phones. You can also make your calls from either extension.

A typical example for internal twinning would be a user who uses both a normal desk phone and also needs a mobile phone while moving around the building.

Your settings are applied to both phones. Similarly, message waiting indication and voicemail access from either phone will be to your mailbox.

If both phones are phones that store your contacts and call history on the system, the contacts and call history on each will be the same.

T = Twinned
A T is shown after your extension name on the phone’s idle display if it is internally twinned with your phone. Calls to you will alert on both phones and can be answered by you at either phone.

Mobile Twinning

Mobile twinning allows your calls to ring at both your phone’s and at another phone’s number, which can include an external number. If you have been configured as a mobile twinning user, you can switch the use of mobile twinning on or off through the phone’s menus and can also change the number to which you are twinned.

Using the phone menus, you can switch the use of mobile twinning on/off and change the destination number for twinned calls.

14.4.1 Mobile Twinning Control

This menu option is only available if you have been configured by the system administrator to be able to use mobile twinning.

Setting a button to the Twinning function is recommended—contact your system administrator. Such a button allows you to transfer calls to your twinning destination, retrieve calls from the twinning destination, and access the menu options below to set the twinning destination number and switch twinning on/off.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Mobile Twinning. Press Select.
If no twinning number has been set, the menu will prompt you to enter a number.
When a number has been entered, you can access the Enable and Disable soft keys to turn use of mobile twinning on or off. The Clear soft key removes the existing twinning number in order to allow entry of a new number.

14.4.2 Transferring a Call to Your Mobile

If you have been configured as a mobile twinning user, you can transfer a call to your mobile device using the features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
If necessary, use the up and down arrow keys to highlight Transfer to Mobile. Press Select.

14.4.3 Reclaiming a Twinned Call

When using mobile twinning, you can use the status menu to take back a call that has been redirected to and answered at your mobile twinning destination.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If necessary use the up and down arrow keys to scroll the menu to Mobile Twin Call.
Press Connect.

14.4.4 Switching Twinning Off

If you have been configured as a mobile twinning user, you can use the status menu to switch mobile twinning mode off.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If necessary use the up and down arrow keys to highlight Mobile Twinning. · To clear the setting, press the Off soft key.

Chapter 15. Groups

Your system administrator can include you as a member of a group along with other users. Each group has its own extension number which can be used as the destination for a call.

When a call is made to a group, it is presented to the available group members, either one at a time or all at the same time, until answered by one of the members.

How long a group call will ring at each group member before being presented to the next member is controlled by the group’s own settings. Hunt groups also use voicemail and have their own settings for when an unanswered call should go to the group’s mailbox. For group calls, the hunt group’s voicemail settings are used rather than your settings.

The system administrator can enable a number of hunt group menu options on your phone. Each option is enabled for a selected hunt group or hunt groups of which you are a member:

Enable/Disable Your Group Membership
When your membership of a hunt group is disabled, you no longer receive hunt group calls for that group. You are still a member of the group and can re-enable your membership.
Change the Hunt Group Service Status
Each hunt group can either be in service, in night service, or out of service. When in night service or out of service, the groups calls are redirected to an alternate group, or to voicemail if available.
Change the Hunt Group Fallback Destination
These menus allow you to change the alternate groups used for the group’s calls when it is in night service or out of service status.

Default Short Codes

Short codes are numbers that you can dial to enable and disable various features. The following are default short codes that may be available. However, your system administrator can remove and change the short codes available to you or all users.

Night Service Status On: 20N#
Set a hunt group into night service status by entering its extension number (N).
Night Service Status Off: 21N#
Take a hunt group out of night service status by entering its extension number (N).

15.1 Group Membership

Only the system administrator can change a group, the group members, or group settings. However, you can be
provided with options to enable or disable your group membership. While membership to a group is disabled, you will not
receive any group calls for that group.

15.1.1 Group Membership On/Off (Status Menu)

Your system administrator can grant you the ability to enable/disable your membership to a group through the Status menu. When your membership to a group is disabled, you do not receive group calls for that group.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if
shown.
Use the up and down arrow keys to highlight the hunt group name and your current membership status (Enabled or Disabled).
Press the Enable or Disable soft key to change the status of your membership to that group.
Press Exit.

! The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

15.1.2 Group Membership On/Off (Features Menu)

You may be able to enable or disable your group membership for some of the groups to which you belong.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Group. Press Select.
Use the up and down arrow keys to highlight Membership. Press Select.
Use the up and down arrow keys to scroll through the list of hunt groups you can configure.
To change your membership to the highlighted group press Change. To change your membership to all groups, press More and then press either All Ena or All Dis.

! The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

15.2 Group Service Status and Fallback

Group Service Status
A hunt group can be in one of the following service modes:
In-Service
The groups operates as normal, distributing calls to available members of the group.
Night Service
The group is in ‘night service’ mode. Calls are redirected to its night service fallback group if set, otherwise
to voicemail if available.
A hunt group can also be put into and out of night service automatically by the telephone system using a
time profile. If that is the case, the night service state cannot be overridden using manual controls.
Out of Service
The group is out of service. Calls are redirected to its out of service fallback group if set , otherwise to
voicemail if available.
Fallback Group
For the night service and out of service states, the hunt group can be configured with a fallback destination to which its group calls are redirected. This destination is another hunt group. If no fallback destination is set, the group’s voicemail is used (if available). Separate night service and out-of-service fallback destinations can be set for the group.

Display Icon

O = Out of Service
When a group is set to night service mode, all members of that group retain an ‘out of service’ status indicated by an O on the idle display. Calls are diverted to the group’s fallback, if set. Otherwise, the calls are sent to voicemail (if available).
! The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

15.2.1 Changing the Group Service Status (Features Menu)

Using the Features menu you may be able to change the service status of some groups to which you belong.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Group. Press Select.
Use the up and down arrow keys to highlight State. Press Select.
Use the up and down arrow keys to scroll through the list of hunt groups you can configure. Use All Groups for all the groups you can configure. The soft keys available will vary depending on whether a particular or all groups is selected and the current state of the selection.

All Groups
In Service
The groups operates as normal, distributing calls to available members of the group.
Night Service
The group is in ‘night service’ mode. Calls are redirected to its night service fallback group if set, otherwise
to voicemail if available.
A hunt group can also be put into and out of night service automatically by the telephone system using a
time profile. If that is the case, the night service state cannot be overridden using manual controls.
Out of Service
The group is out of service. Calls are redirected to its out of service fallback group if set , otherwise to voicemail if available.
Particular Group
Change
Change the status of the selected group.
Save
Exit the menus.
! The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

15.2.2 Changing the Group Service Status (Status Menu)

If the system administrator has allowed you, you can change the service state of a group through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight the hunt group name and your current membership status.
Select the required state using the soft keys:

In-Service
The group operates as normal, distributing calls to available members of the group.
Night Service
The group is in ‘night service’ mode. Calls are redirected to its night service fallback group if set, otherwise to voicemail if available.
A hunt group can also be put into and out of night service automatically by the telephone system using a
time profile. If that is the case, the night service state cannot be overridden using manual controls.
Out of Service
The group is out of service. Calls are redirected to its out of service fallback group if set, otherwise to voicemail if available.
!
The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.
106

15.2.3 Changing the Group Fallback

You may be able to use the Features menu to change the fallback group destination for some of the hunt groups of which you are a member.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Group. Press Select.
Use the up and down arrow keys to highlight Fallback. Press Select.

Use the left and right arrow keys to switch between altering night service (NS) or out of service (OOS) settings.
Use the up and down arrow keys to scroll through the list of hunt groups you can configure in the current mode.
To change the setting of the currently highlighted hunt group press Edit.
To change the setting of all the hunt groups press More and then press Edit All.
! The system administrator is able to configure whether you have access to the Membership, State and
Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

Chapter 16. Button Features

Functions can be assigned to the phone’s feature buttons by your system administrator or by yourself using self-administration. Note how you cannot replace features assigned to buttons by your system administrator but you can replace other features. Note also that there are features that the system administrator can assign that are not available for you to assign. This guide includes only the features that are available for you to assign if required.

These options are only available if configured by your system administrator.

Button Lamps

The use of the button lamp or icon will depend on the action associated with the button.

Fixed Buttons

On all the phones, the programmable button features appear below the call appearance buttons. The screen can be scrolled to display further buttons. For the 9650 phones, some of the programmable buttons remain permanently visible even if the display is scrolled. On the 9641 phones, you can select to have some of the programmable buttons permanently visible.

16.1 Editing Your Programmable Buttons

Self Administer is used to select and apply a function to a feature key. It can be used to replace or delete existing functions.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Self-Administer. Press Select.
Enter your security PIN and press Done.
On 9621 and 9641 phones, select Button Features. Use the up and down arrow keys to scroll through the list of current functions assigned to each button.

To remove the existing function from a button press Erase.
You can also press More and use the Copy and Paste options to copy the settings of an existing button to
another button.
To assign a function to the highlighted button press Replace.
Select the required function from the list and press Select.
Depending on the function, you may need to enter some information such as a target extension number.
The button will be given a default label. To change the label, press More and then select Label. Use the keyboard to enter the text you want to display for the button label. Note that the label is only shown while editing the label and after you exit the administration menu.

When completed press Back.

16.2 Features

There are a wide range of features that can be assigned to the buttons. This guide only lists those that you can assign to a button using the self-administer menu. Functions that can only be assigned by your system administrator will be explained by the system administrator.

Abbreviated Dial
Absence Text
Account Code
Call Forward All
Call Park
Call Park To Other
Call Pickup
Call Pickup Any
Conf Meet Me
Drop Call
Flash Hook
Group BLF
Internal Auto Answer
Page
Park and Page
Ringer Off
Self Administer
Send All Calls
Suppress Digits
User BLF
Twinning

Some actions are not supported on all phones. However, they may be set for users who hot desk between different types of phone. On 9621 and 9641 phones, those functions marked by a * can be assigned to a quick touch line button on the phone’s home screen.

16.2.1 Abbreviated Dial

This action can be used as a speed dial button. While setting up the button, enter the number you would like it to dial.

You can enter a partial number and complete the dialing after pressing the button. For example, you can pre-program a button with a particular international dialing code.

16.2.2 Absence Text

Set or clear an absence text message for display on your phone. This text also appears on the display of the phone making the incoming call. When setting the message, you can select from a number of pre-configured messages and then add your own text if you want.

16.2.3 Account Code

This action can be set with or without an account code.

If the button is set with an account code, that account code is applied to the current call when the button is pressed.

If the button is set without an account code, pressing the button will display the enter account code menu.

16.2.4 Auto Answer

A button configured with this action can be used to switch ‘the internal auto-answer on or off. When ‘the internal auto-answer is on, the button’s red lamp is lit. Pressing the button again turns ‘the internal auto-answer off.

16.2.5 Call Forward All

A button with this action can be used to switch ‘forwarding unconditional’ on/off.

If set with a preset number, that number is used as the forwarding destination.

If set without a number, when the button is pressed you will be asked to confirm your existing ‘forward unconditional’ destination number or to enter a new number.

The button’s red lamp is lit when forwarding is enabled. On touch screen phones an icon is displayed. The button can be pressed again to switch ‘forward unconditional’ off.

16.2.6 Call Park

A button set to this action can be used to park and unpark calls. The button can be set with or without a park slot number.

When associated with a specific park slot number, the button can park and unpark a call from that park slot. When a call has been parked in that park slot, the button’s lamp flashes. Green if the call was parked using that button, red if parked by another method. Pressing the button again retrieves the call.
When not associated with a specific park slot number:
- If pressed while you have a call connected, that call is parked using a park slot number assigned by the system based on your extension number.
- If pressed while you have no call connected, your phone displays details of your parked calls and allow you to unpark a selected call.
- When you have calls that you parked (other than Park & Page) or others parked against your extension, the button’s lamp flashes.

16.2.7 Call Park to Other

A button set with this action can be used to park a call against another extension. The park slot number used will be based on your extension number.

The button can be set with a target user number or left blank for number entry when the button is pressed. The button’s red lamp is lit when a call is parked. The button can be pressed again to retrieve the call.

16.2.8 Call Pickup

Answer a call ringing a user or hunt group.

The target user or group number from which to pick up a call can be set when the button is configured. If no number is set, pressing the button will display a menu for number entry.

16.2.9 Call Pickup Any

Answer a call currently ringing on the telephone system.

16.2.10 Conf Meet Me

A button programmed to this feature allows you to start or enter a conference by entering the conference ID.

16.2.11 Drop Call

This action can be used to drop your current call without having to highlight it on the display.

16.2.12 Flash Hook

A button configured for this action will send a flash hook signal to a currently connected analog line.

16.2.13 Group BLF

A button can be programmed to indicate if there are any calls to a group waiting to be answered. A red flashing lamp indicates that there are calls waiting for the hunt group. Press the button to pickup the longest waiting call.

16.2.14 Page

A button configured with this action can be used to make a page call.

The button can be configured with the target user or group for the page. If configured without a number, pressing the button will display a menu for number entry before making the page call.

16.2.15 Park and Page

If your system administrator has configured your system for Park & Page, this button allows you to use the feature to park calls and announce the parked call to other users.

16.2.16 Ringer Off

A button configured with this action can be used to turn your phone’s ringer on or off.

When you turn the ringer off the visual alerting is also turned off. When the ringer has been turned off, the button’s red lamp is lit. Pressing the button again will turn the ringer on.

16.2.17 Self Administer

A button configured for this action can be used to access the Self Administer menu.

16.2.18 Send All Calls

A button configured with this action can be used to switch ‘do not disturb ‘ on or off. When ‘do not disturb’ is on, the button’s red lamp is lit or a red warning icon is displayed. Pressing the button again turns ‘do not disturb’ off.

16.2.19 Suppress Digits

Masks the display of digits as you dial them on the phone. Dialed digits are replaced with an s character. The button is used to switch the suppression on/off. When ‘suppress digits’ has been set, the button’s red lamp is lit. Pressing the button again cancels the suppression.

If en-block dialing is active you will see the digits as you dial them. When you make the call the digits will be suppressed.
When the option to suppress digits is used, the call is not recorded in the call log.

16.2.20 Twinning

A button configured for this feature allows you to control your phone’s mobile twinning operation. This is only useable if your system administrator has configured you for mobile twinning.

If pressed when the phone is idle, the phone displays the mobile twinning menu. You can use the menu to switch mobile twinning on/off and to setting the twinned destination.
If pressed while a twinned call is connected to the twinned destination, the system attempts to reclaim the call.
If pressed while connected to a call on the phone, the system attempts to transfer the call to the twinned destination. You do not need twinning switched on to use this feature.

16.2.21 User BLF

This type of button can be used to monitor the status of another user. The lamp’s state will indicate the status of the user.

Off = Available
Pressing the button will make a call to the user. In addition to calling the user, you can use the user button to transfer calls to the user or to start a conference with the user.
Slow Flash = Ringing
Pressing the button will display options to pickup the call.
Fast Flash = On a Call
Pressing the button will display a number of options:
- Call – Call the user.
- Message – Cause a single burst of ringing on the user’s phone. They will also see the message “Please Call” followed by your extension number.
- Voicemail – Call the user’s voicemail mailbox to leave a message.
- Auto Callback – Set an automatic callback on the user. The callback will occur when the user ends their current call.

The following options are only available if configured for you by your system administrator:

Drop Call – Disconnect the user’s current call.
Acquire – Seize the user’s current call.
Intrude – Join the user’s current call, turning it into a conference call.
Listen – Start silent monitoring of the user’s call.

Chapter 17. Home Screen

17. Home Screen

The 9621 and 9641 phones have a home screen that contains a number of icons for accessing functions. Some of the icons are configured by your system administrator, some are fixed. You can add up to 8 icons to access special functions.

The screen is accessed by pressing the HOME key. To exit the screen press the PHONE key.

Display the Home Screen When Idle

The home screen used on 9621 and 9641 phones can be set to automatically display if the phone is idle for over 10 minutes.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Select Return to Home Screen to change the current setting for that function.
Press Save.

17.1 Editing Your Home Screen

There is a wide range of actions that can be assigned to the buttons. This guide only includes details of those that you can assign to a button using the self-administer menu. Functions that can only be assigned by your system administrator will be explained by the system administrator.

Abbreviated Dial
Absence Text
Auto Intercom
Call Forward All
Call Pickup
Call Pickup Any
Page
Self Administer
Send All Calls

Those functions marked as * can also be assigned to programmable buttons.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down keys to highlight Self-Administer. Press Select.
Enter your security PIN and press Done.
Select Home Screen Favorites.
Use the up and down keys to scroll through the list of current functions assigned to each button.

To remove the existing function from a button press Erase.
You can also press More and use the Copy and Paste options to copy the settings of an existing button to another button.
To assign a function to the highlighted button press Replace.
- Select the required function from the list and press Select.
- Depending on the function, you may need to enter some information such as a target extension number.
The button will be given a default label. To change the label, press More and then select Label. Use the keyboard to enter the text you want to display for the button label. Note that the label is only shown while editing the label and after you exit the administration menu.

7. When completed press Back.

17.2 Abbreviated Dial

This action can be used as a speed dial button. While setting up the button, enter the number you would like it to dial.

You can enter a partial number and complete the dialing after pressing the button. For example, you can pre-program a button with a particular international dialing code.

17.3 Absence Text

17.4 Auto Intercom

Make a call to another extension that will be connected without ringing if the other phone supports ‘auto-answer.’

17.5 Call Forward All

A button with this action can be used to switch ‘forwarding unconditional’ on/off.

If set with a preset number, that number is used as the forwarding destination.

If set without a number, when the button is pressed you will be asked to confirm your existing ‘forward unconditional’ destination number or to enter a new number.

The button’s red lamp is lit when forwarding is enabled. On touch screen phones an icon is displayed. The button can be pressed again to switch ‘forward unconditional’ off.

17.6 Call Pickup

Answer a call ringing a user or hunt group.

The target user or group number from which to pick up a call can be set when the button is configured. If no number is set, pressing the button will display a menu for number entry.

17.7 Call Pickup Any

Answer a call currently ringing on the telephone system.

17.8 Page

A button configured with this action can be used to make a page call.

The button can be configured with the target user or group for the page. If configured without a number, pressing the button will display a menu for number entry before making the page call.

17.9 Self Administer

A button configured for this action can be used to access the Self Administer menu.

This option is only available if configured by your system administrator.

17.10 Send All Calls

Chapter 18. Phone Settings

18. Phone Settings

Pressing the MENU/HOME key accesses a menu that can be used to control various phone settings. These are mainly settings stored by the phone rather than user settings that move with you.

General

Mobile Twinning
Withhold Number
Redial Mode
Backup/Restore
Debug Mode
En-Bloc Dialing

Display Controls

Display Brightness
Display Contrast · Call Timer
Show Last Call Duration
Display Language
Show Waiting Calls
Exit Menu Inactivity Timer (Auto Return)
Quick Touch Lines

Sounds

Button Clicks
Error Tones
Ringer Volume
Handset Volume
Headset Volume
Speaker Volume
Automatic Gain Control
Default Audio Path

Ringer Controls

Switch the Ringer On/Off
Flash the message lamp for calls (Visual Alerting)
Coverage Ring
Ring Sound
Ring Volume
Internal Auto Answer

18.1 Mobile Twinning

This menu option is only available if you have been configured by the system administrator to be able to use mobile twinning.

Setting a button to the Twinning function is recommended—contact your system administrator. Such a button allows you to transfer calls to your twinning destination, retrieve calls from the twinning destination, and access the menu options below to set the twinning destination number and switch twinning on/off.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Forward. Press Select.
Use the up and down arrow keys to highlight Mobile Twinning. Press Select.
If no twinning number has been set, the menu will prompt you to enter a number.
When a number has been entered, you can access the Enable and Disable soft keys to turn use of mobile twinning on or off. The Clear soft key removes the existing twinning number in order to allow entry of a new number.

18.2 Withhold Number
You can select to withhold your number on external calls. Note that this option may not be supported in all situations. It may depend on the configuration of your phone system and options supported by your telephone line provider.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down menu keys to highlight Withhold Number.
Press Change to switch the option On or Off.
Press Save.

18.3 Redial Mode

You can select whether your phone uses the redial list or last call redial mode.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Redial Action.
The current mode, Open Call Log or Last Dialed is displayed.

Open Call Log
If this mode is selected, pressing Redial will display a menu of the most recent outgoing calls in your call log. You can select the call that you want to redial and perform a number of other functions.
Last Dialed
If this mode is selected, pressing Redial will immediately repeat the most recent outgoing call in your call log. None of the other redial functions will be accessible.

6. Press Change to change the mode.
7. When the desired mode is displayed, press Save.

18.4 En-Bloc Dialing

En-bloc dialing allows you to compose and edit the number to dial on your phone’s display before it is sent to the phone system to be dialed.

You can enable or disable your en-bloc dialing setting through the phone’s Features menu.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight En-Bloc Dial.
Use Change button to select On or Off.

18.5 Auto Lock

18.6 Ringer Controls

This section covers controls for adjusting the ringing used by your phone. · Disabling the ringer

Flash the message lamp for calls (Visual Alerting)
Coverage Ring
Ring Sound
Ringer Volume
Internal Auto Answer

Calls are presented with a number of different ring patterns.

Internal Calls: Repeated single ring.
External Calls: Repeated double ring.
Ringback/Return Calls: Repeated single-ring followed by two short rings. This type of ring is used for calls that are returning to your phone. For example, a call that you put on hold and which is returning due to being left on hold too long.
Coverage Ring: Variable. You can also adjust the ringing used for call coverage and bridged appearance buttons. The options are normal ringing, an abbreviated ring (a non-repeated single ring), and no ring.
Attention Ring: Variable. The system administrator can adjust the ring used for new calls when you are already talking to a caller. The
options are an abbreviated ring (a non-repeated single ring) and no ring.
- For calls alerting on a call coverage or bridged appearance button when you are already on a call, the shorter of the coverage ring or attention ring settings is used.

The system administrator can also adjust when ringing is used for each specific appearance button. The ringing can be immediate, delayed for a set time, or off.

18.6.1 Disabling the Ringer

This option can be used to turn off the ringer for all calls. If set to no ring, this disables both the phone’s audible alerting and visual alerting. On some 9600 Series phones, when you disable the ringer, the status indication line displays an icon.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Disable Ringer.
Press the Change soft key to change the setting. Selecting On will turn the ringer off.

18.6.2 Visual Alerting

The message waiting for lamp at the top-right corner of the phone can also be used to indicate when you have a call alerting your phone. The lamp is flashed to indicate a call waiting to be answered.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Visual Alerting.
Press the Change soft key to change the setting.
When completed, press the Save soft key.
Press the Back / Exit soft keys to exit the menus.

18.6.3 Coverage Ring

If you have any bridged appearance and or call coverage buttons, you can set the type of ringing (coverage ring) that should be used when a call alerts on any of those buttons. The options are to use normal ringing, a single non-repeated ring (abbreviated ring), or no ring. The coverage ring setting is only used if you do not already have a connected call. If you already have a connected call in progress, the shorter of the coverage ring and attention ring settings is used.

This is a user setting that will move with you if you hot desk another phone.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Coverage Ring.
Press the Change soft key to change the setting.

Ring – Use normal ringing.
Abbreviated – Use a single non-repeated ring (abbreviated ring).
Off – No ring.

18.6.4 Ring Sound

As well as ring patterns, you can change the sound of the ring tone used:

Note: The default ring tone is set by the administrator.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Personalized Ringing. Press Select.

Press Rich or Classic to alternate between rich and classic ring tone options.
Use the up and down arrow keys to scroll through the different available ring tones.
Clicking on a ring tone will play that ring tone through the phone’s speaker.
Press the Play soft key to listen to the currently displayed ring tone.
Press Other to hear a different version of the ring tone.
To make the currently selected ring tone the ring tone for the phone, press the Save soft key.
To leave the menu without making any changes press the Cancel soft key.

5. Press Back / Exit to exit the menus.

18.6.5 Ringer Volume

You can adjust the ringer volume while the phone is idle or while it is ringing. The status indication line displays an icon followed by eight bubbles that represent the volume level. When no ringer is audible, the indication line displays an icon.

With the phone idle or ringing, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

18.6.6 Internal Auto Answer

You can select to have internal calls automatically connected if you are not already on a call. The call will be connected, after the phone gives a brief tone, using either the phone’s speaker or the headset as set by the phone’s audio path setting.

Press Features.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Internal Auto-Answer.
Press the Change soft key to change the setting.

This function can be assigned to a feature button configured with the Internal Auto Answer action. The button lamp will indicate when ‘internal auto answer is on.

18.7 Display Controls

This section covers controls for adjusting the phone’s display and the information shown on the display.

Display Brightness
Adjust the brightness of the display.
Display Contrast
Adjust the contrast of the display.
Call Timer
Adjust whether the ring/call time is displayed for calls on appearance buttons.
Show Last Call Duration
Display the duration of a call for a few seconds after the call is ended.
Display Language
Select the language used for the phone’s menus.
Auto Display Waiting Call
If, when already on a call, there is another call waiting to be answered, automatically display the call information of the waiting call.
Exit Menu Inactivity Timer (Auto Return)
Return to the normal call display after a period of inactivity in a menu.
Quick Touch Lines
On 9621 and 9641 phones you can display a fixed set of buttons at the bottom of the home screen.

18.7.1 Display Brightness

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Brightness. Press Select.
Use the left and right arrow keys to adjust the brightness as required.
When completed, press the Save soft key.
Press Back / Exit to exit the menus.

18.7.2 Display Contrast

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Contrast. Press Select.
Use the left and right arrow keys to adjust the brightness as required.
When completed, press the Done soft key.
Press Back / Exit to exit the menus.

18.7.3 Last Call Duration Display

As an alternate to call timer display, you can have the phone briefly (4 seconds) display the duration of the call after it is ended.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Show Last Call Duration.
Press Change to change the setting between On or Off.
Press the Save soft key.

18.7.4 Home Screen Display

The home screen used on 9621 and 9641 phones can be set to automatically display if the phone is idle for over 10 minutes.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Select Return to Home Screen to change the current setting for that function.
Press Save.

18.7.5 Call Timer Display

When you have calls alerting on appearance buttons, the phone can include a timer in the appearance details shown on the display. The timer shows how long the call has been alerting and, if you answer the call, resets to show how long the call has been connected. The timer will also show how long a call has been on hold when you hold the call.

You can turn the timer display on or off. Turning it off provides more space for other call details on the display.

9621 and 9641 Phones

By default, when you are connected on a call, the display will show details of that call. In order to see details of another call, such as a held call or a waiting call, you need to scroll the display using the up and down arrow buttons.

Using this option, you can select to have the current call display automatically toggle between details of the current call and details of the waiting call.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Call Timer.
Press Change to change the setting between On or Off.
Press the Save soft key.

Other 9600 Phones

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Display Call Timer.
Press Change to change the setting between On or Off.
When completed, press the Save soft key.
Press Back / Exit to exit the menus.

18.7.6 Display Language

The system administrator can configure which languages are available for use by the phone for its own menus. Up to five languages can be made available.

Through the phone’s menu, you can select which of those languages the phone should use.

Note that many of the messages displayed on the phone use text sent from the telephone system. They will use the default language of the telephone system unless the system administrator has set your extension to use a specific language supported by the phone system.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Language. Press Select.
Use the up and down arrow keys scroll through the different languages available.
To select the language currently highlighted, press Select.
When completed, press the Save soft key.
Press Back / Exit to exit the menus.

18.7.7 Auto Display Waiting Call

By default, when you are connected on a call, the phone shows details of that call and soft key actions you can perform for that call. In order to see details of a waiting call, you need to scroll the display using the up and down arrow buttons.

You can opt to have the phone automatically show details of a waiting call when one alerts the phone and soft key actions that you can perform on the waiting call. If you use the scroll keys to return the display focus to the currently connected call, the focus automatically returns to the waiting call after a few seconds.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Auto Display Waiting Call.
Press Change to change the setting.
Select one of the following settings as desired:

Off – Show details of the current call only. · On – Automatically show the details of a waiting call.
7.Press the Save soft key.

18.7.8 Inactivity Timer (Auto Return)

You can set a timer that will return the phone to its normal call display after a set period of phone inactivity. By default, the phone will be set to auto return after 60 seconds.

Note that the timer is not applied to all menus. For example, it is not applied to the A-menu and to the Visual Voice menu. It is also not applied to the System Admin section of the Features menus.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Phone Screen Settings. Press Select.
Use the up and down arrow keys to scroll the display to Auto Return(s).
Press Change to change the setting.

Disabled
Do not use the inactivity timer.
30 / 60
Apply the inactivity timer after the selected number of seconds.

6. Press the Save soft key.

18.7.9 Quick Touch Lines

For 9621 and 9641 phones, the phone can display one or two rows of fixed buttons across the bottom of the call display screen, each row containing four buttons. ‘Fixed’ means the rows do not scroll out of view when the rest of the screen is scrolled.

Your system administrator can select how many lines the phone shows by default. However, you can then select the number that you prefer or to have no lines.

Note: Only users with ‘self administer’ privileges can configure quick touch line buttons. <<<need TUI Self Administration privilege to change this setting>>>

Quick touch line buttons match the programmable feature buttons supported by IP Office, but certain features can only be configured by an administrator. The available user-programmable features include:

Abbreviated Dial
Call Pickup Any
Absence Text · Page
Call Forward All
Self Administer
Call Pickup
Send All Calls

If you attempt to configure a quick touch line button to a feature not supported by IP Office, the display for that button will read “Invalid.” The assigned quick touch features are displayed left to right, top to bottom.

To activate quick touchlines:

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight Phone Screen Settings. Press Select.
Use the up and down arrow keys to scroll the display to the option Quick Touch Lines.
Press Change to change the setting.

Off = No quick touch rows.
1 = Display one row of four quick touch buttons across the bottom.
2 = Display two rows of four quick touch buttons across the bottom.
Auto = Display 1 row when using a 9621, 2 rows when using a 9641.

6. Press the Save soft key.

To configure a quick touch line button:

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down keys to highlight Self Administer. Press Select.
Enter your security PIN and press Done.
On 9621 and 9641 phones, select Button Features. Use the up and down arrow keys to scroll through the list of current functions assigned to each button.

To remove the existing function from a button press Erase.
You can also press More and use the Copy and Paste options to copy the settings of an existing button to another button.
To assign a function to the highlighted button press Replace.
- Select the required function from the list and press Select.
- Depending on the function, you may need to enter some information such as a target extension number.
The button will be given a default label. To change the label, press More and then select Label. Use the keyboard to enter the text you want to display for the button label. Note that the label is only shown while editing the label and after you exit the administration menu.

5. When completed press Back.

18.8 Volume and Sound

This section covers controls that relate to volume and to the various sounds that your phone uses. These are in addition to the available ringer controls.

Button Click
Turn the phone menu key click on or off.
Error Tones
Turn the phone menu error tones on or off.
Ringer Volume
Adjust the volume of the ringer used by the phone.
Handset Volume
Adjust the incoming call volume heard through the phone’s handset.
Headset Volume
Adjust the incoming call volume heard through a headset attached to the phone.
Speaker Volume
Adjust the incoming call volume heard through the phone’s speaker.
Automatic Gain Control
Switch automatic gain control on or off.

Note: The system administrator can configure your phone to reset its volume after each call.

18.8.1 Button Clicks

While using the phone menus, the phone can provide a key press confirmation click sound. This can be disabled.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Button Clicks.
Press Change to change the setting between On or Off.
When completed, press the Save soft key.
Press Back / Exit to exit the menus.

18.8.2 Error Tones

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.
Use the up and down arrow keys to highlight Error Tones.
Press Change to change the setting between On or Off.
When completed, press the Save soft key.
Press Back / Exit to exit the menus.

18.8.3 Ringer Volume

With the phone idle or ringing, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

18.8.4 Handset Volume

While talking via the handset, you can adjust the volume of the incoming call. The status indication line displays an icon followed by eight bubbles that represent the volume level.

With the call connected on the handset, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

18.8.5 Headset Volume

While talking via the headset, you can adjust the volume of the incoming call. The status indication line displays an icon followed by eight bubbles that represent the volume level.

With the call connected on the headset, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

18.8.6 Speaker Volume

With the call connected on the speaker, press the key.
Use the + plus and – minus keys to adjust the volume.
The display returns to normal after a few seconds.

18.8.7 Automatic Gain Control

When using automatic gain control (AGC), the phone tries to maintain a constant audio level even if the incoming call changes between loud and quiet.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Advanced Options. Press Select.
Use the up and down arrow keys to highlight Automatic Gain Control. Press Select.

Use the up and down arrow keys to switch between Handset, Headset, or Speaker settings for AGC.
To change the highlighted setting, press Change.

4. When completed, press Save.

5. Press Back / Exit to exit the menus.

18.8.8 Default Handsfree Audio Path

By default, when you make a call or answer a call without lifting the handset, the audio is played through the phone’s speaker while you speak via the phone’s microphone.

If you have a headset attached, you can change the phone’s behavior so that the audio is played through the headset by default rather than the speaker.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Options & Settings. Press Select.
Use the up and down arrow keys to highlight Call Settings. Press Select.
Use the up and down arrow keys to highlight Audio Path.
Press Change to change the setting between Headset and Speaker.
When completed, press the Save soft key.
Press the Back / Exit soft keys to exit the menus.

18.9 Backup/Restore

If backup/restore has been set up by your system administrator, it is used automatically when you log in and log out of the phone.

Backup/restore is used for the phone settings that you have configured within the menus provided by the phone’s MENU/HOME button. When you log in at another 1600 or 9600 Series phone extension, your phone settings are restored and applied to that phone. They will remain applied to that phone until another user logs in and their phone settings are applied.

By default, your call log and your personal contacts are stored on the telephone system. These will be restored by the telephone system when you log in on another 1600 or 9600 Series phone regardless of whether backup/restore has been configured for the 1600 and 9600 Series phones.

When backup/restore has been configured, the phone menu provides options to manually access backup and restore functions.

Manually Backup Phone Settings
Manually Restore Phone Settings

18.9.1 Backup

If backup/restore has been set up by your system administrator, it is used automatically when you log in and log out of the phone.

In addition, the option below is available to manually trigger a backup of your user settings.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Advanced Options. Press Select.
Use the up and down arrow keys to highlight Backup/Restore. Press Change.
Use the up and down arrow keys to highlight Manual Backup. Press Backup.

! This option is only available if your system administrator has configured backup/restore operation.

18.9.2 Restore

If backup/restore has been set up by your system administrator, it is used automatically when you log in and log out of the phone.

In addition, the option below is available to manually trigger a restore of your user settings.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Advanced Options. Press Select. 3.Use the up and down arrow keys to highlight Backup/Restore. Press Change. 4.Use the up and down arrow keys to highlight Manual Restore. Press Restore. · ! This option is only available if your system administrator has configured backup/restore operation.

18.10 Viewing Information

You can view information about the phone’s settings and current operation. When reporting a problem to your system administrator, they may ask you to provide some of this information to help resolve the problem.

Press the MENU/HOME button and select Settings.
Use the up and down arrow keys to highlight Network Info…. Press Select.
Use the left and right arrow keys to move through the different pages of information.

Audio Parameters
The settings configured for sound and sound devices.
IP Parameters
The IP settings with which the phone has been configured by the installer or by a DHCP server.
Quality of Service
Quality of Service (QoS) measurements for the current call.
Interfaces
The current speed of the phone’s ethernet port and its PC pass-through Ethernet port.
Miscellaneous
Details of the phone and the firmware that it currently has loaded.

4. To return to the parent menu, press the Back soft key.

Chapter 19. Status Menu

19. Status Menu

The Status menu is not always visible. It is shown when you have any special call routing features active; for example, ‘do not disturb’ switched on.

It is also shown if the system administrator has given you the rights to change the status of your hunt group memberships or to change the service status of the hunt groups.

Switching mobile twinning off · View and unpark parked calls
Clear or change a ‘follow me to’ setting
Switch off ‘do not disturb’
Clear or change ‘forward unconditional’
Clear or change ‘forward on no answer’
Clear or change ‘forward on busy’
Clear or change ‘follow me here’ settings
Change hunt group membership status
Change hunt group service status
View system alarms

19.1 Do Not Disturb

You can use the Status menu to switch off ‘do not disturb.’

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If necessary use the up and down arrow keys to highlight Do Not Disturb. To clear the ‘do not disturb’ setting, press the Off soft key.

19.2 Follow Me To

If you have set a ‘follow me to’ destination for calls to your phone, you can clear or change the setting through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Follow Me To.

To clear the ‘follow me to’ setting, press the Clear soft key.
To change the destination of the setting, press the Details soft key.

19.3 Follow Me Here

If other users has a ‘follow me’ set to you phone, you can clear or change the setting through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Follow Me Here. There will be a separate entry for each user.

To clear the ‘follow me to’ setting, press the Clear soft key.
To change the destination of the setting, press the Details soft key. · Use the menu to add or remove users.
Use the up and down arrow keys to scroll through the names.
- To remove a user, press the Clear soft key.
- To add a user, press the Add soft key.
  - Dial the number of another user. When it matches a user, their name is displayed. Alternatively, use
    the Dir soft key to select a user from the directory.
  - Press the Save soft key to set the ‘follow me here.’

19.4 Forward On Busy

If your phone is set to ‘forward on busy,’ you can clear or change the forward settings through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd Busy.
To switch the forward off press Off.
To change the forward setting press Details.

Use the up and down arrow keys to scroll through the menu options.
- To switch ‘forward on busy’ on or off, highlight Fwd Busy and press On or Off.
- To switch ‘forward on no answer’ on or off, highlight Fwd No Answer and press On or Off.
- To select which calls are forwarded highlight Call Type. Press Change to change the option between All Calls or External Calls Only.
- To change the destination highlight Destination and press Edit. Enter the number and press Select.
Press Save to save any changes.

19.5 Forward On No Answer

If your phone is set to ‘forward on no answer ‘ you can clear or change the forward settings through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd No Answer.
To switch the forward off press Off.
To change the forward setting press Details.

Use the up and down arrow keys to scroll through the menu options.
- To switch ‘forward on busy’ on or off, highlight Fwd Busy and press On or Off.
- To switch ‘forward on no answer’ on or off, highlight Fwd No Answer and press On or Off.
- To select which calls are forwarded highlight Call Type. Press Change to change the option between All Calls or External Calls Only.
- To change the destination highlight Destination and press Edit. Enter the number and press Select.
Press Save to save any changes.

19.6 Forward Unconditional

You can clear or change your ‘forward unconditional settings through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd Uncon.

To switch off ‘forward unconditional,’ press the Off soft key.
To change the forwarding settings, press the Details soft key.
- Use the up and down arrow keys to scroll through the editing options.
  - Use the left and right arrow keys to switch the forwarding on or off.
  - Use the left and right arrow keys to select which calls should be forwarded. The options are External Only, External and Group, Non Group Calls, and All Calls.
  - Select edit to change the number to which calls are forwarded.

19.7 Forwarded Here

This option allows you to see the names of users who are currently forwarding calls to you. It includes ‘forward unconditional,’ ‘forward on no answer,’ and ‘forward on busy.’ A separate entry is shown for each user.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight Fwd To Here.

19.8 Group Membership

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight the hunt group name and your current membership status (Enabled or Disabled).
Press the Enable or Disable soft key to change the status of your membership to that group.
Press Exit.

19.9 Group Service Status

If the system administrator has allowed you, you can change the service state of a group through the Status menu.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
Use the up and down arrow keys to highlight the hunt group name and your current membership status.
Select the required state using the soft keys:

In Service
The groups operates as normal, distributing calls to available members of the group.
Night Service
The group is in ‘night service’ mode. Calls are redirected to its night service fallback group if set, otherwise to voicemail if available.
- A hunt group can also be put into and out of night service automatically by the telephone system using a time profile. If that is the case, the night service state cannot be overridden using manual controls.
Out of Service
The group is out of service. Calls are redirected to its out of service fallback group if set, otherwise to voicemail if available.
! The system administrator is able to configure whether you have access to the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.

19.10 Mobile Twinning

If you have been configured as a mobile twinning user, you can use the status menu to switch mobile twinning mode off.

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If necessary use the up and down arrow keys to highlight Mobile Twinning. · To clear the setting, press the Off soft key.

19.11 Parked Calls

Press the Status soft key if shown. To access the Status menu during a call, press the PHONE key and then press the Status soft key if shown.
If you have any parked calls, the Parks option is displayed. The option is not present if you do not have calls parked against your extension.
Press the Details soft key.
Use the up and down arrow keys to scroll through the parked calls.
To unpark a particular call, press the Connect soft key.

Access Control

Your system administrator can configure whether you can access this menu option. See Menu Access Control.

19.12 System Alarms

If you have been configured as a system administrator (also called a system phone user), an S on the phone’s display indicates a system alarm message. While you are not expected to be able to fix the error causing the alarm, the error message allows you to report the problem to your system administrator.

Memory Card Failure
There is a problem with one of the memory cards used by the telephone system. Selecting Admin will take you to the system administration menu where you can check the status of the memory cards.
Expansion Failure
There is a problem with one of the external expansion modules attached to the telephone system.
Voicemail Failure
The voicemail system is not available.
Voicemail Almost Full
The voicemail system is nearly out of storage space for any new messages, prompts, or recordings.
Voicemail Full
The voicemail system cannot store any new messages, prompts, or recordings.
License Key Failure
There is a problem with the memory card used to license features and applications.
System Boot Error
The telephone system has encountered an error while restarting.
Corrupt Date/Time
There is an error in the date or time being used by the system. Selecting Admin will take you to the system administration menu where you can change the date and time.

Chapter 20. Short Codes

20. Short Codes

These are useful as they can be dialed from any phone on the system. For example, this allows you to log in at a basic analog extension and still control a number of features.

Some shortcodes require you to enter some information when you dial them, typically an extension number. That is indicated by N in the shortcodes shown below.

Park/Unpark

Park Call: *37*N#
Parks the held call using the park number dialed in place of N.
Unpark Call: *38*N#
Unpark the call parked using the park number N. Call Pickup
Pickup Any Call: *30
Answer a call ringing on the telephone system.
Pickup a Group Call: *31
Answer a call ringing a group of which you are a member. You can use this even if your group membership is currently set to disabled.
Pickup a Users Call: *32*N#
Pickup a call ringing a user’s extension number (N).
Pickup a Group Members Call: *53*N#
Pickup a call ringing the members of a group (N). This does not necessarily have to be a group call.

Conference

Conference Held Calls: *47
Start a conference between yourself and any calls that you have on hold.

Do Not Disturb

Switch Do Not Disturb On: *08
Set your phone to ‘do not disturb.’
Switch Do Not Disturb Off: *09
Switch off ‘do not disturb.’
Add a Do Not Disturb Exception Number: *10*N#
Add a number (N) to your list of ‘do not disturb’ exceptions.
Delete a Do Not Disturb Exception Number: *11*N#
Remove a number (N) from your list of ‘do not disturb’ exceptions.
Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).

Follow Me

Follow Me Here: *12*N#
Dialed at the extension to which you want your calls redirected. Use your own extension number (N) when dialing the short code.
Follow Me Here Cancel: *13*N#
Dialed at the extension from which you had redirected calls. Use your own extension number (N) when dialing the short code.
Follow Me To: *14*N#
Dialed at your phone. Dial the extension number (N) to which you want your calls redirected. You can dial just *14# to cancel follow me.
Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).

Forwarding

Cancel All Forwarding: *00
Switch off any forwarding (includes ‘forward unconditional,’ ‘forward on busy,’ ‘forward on no answer,’ ‘follow me,’ and ‘do not disturb’).
Set the Forward Unconditional Destination: *07*N#
Set the destination number (N) for ‘forward unconditional’ when it is switched on.
- Switch Forward Unconditional On: *01
  Switch on ‘forward unconditional.’ A destination must have been set.
- Switch Forward Unconditional Off: *02
- Include Hunt Group Calls in Forward Unconditional: *50
- Exclude Hunt Group Calls from Forward Unconditional: *51
Set the Forward On Busy/No Answer Destination: *57*N#
Set the destination number (N) for ‘forward on busy’ and ‘forward on no answer.’ If no number has been set, those functions will use the ‘forward unconditional’ number if set.
- Switch Forward On Busy On: *03
- Switch Forward On Busy Off: *04
- Switch Forward on No Answer On: *05
- Switch Forward on No Answer Off: *06

Hunt Group

Night Service Status On: *20*N#
Set a hunt group into night service status by entering its extension number (N).
Night Service Status Off: *21*N#
Take a hunt group out of night service status by entering its extension number (N).

Login

Log In: *35*N*P#
Log in to a phone using your extension number (N) and login code (P).
Log Out: *36
Log yourself out from the phone where you are currently logged in.

Voicemail

Check Messages: *17
Access mailboxes to check for messages.
Voicemail On: *18
Allow voicemail to be used to answer calls.
Voicemail Off: *19
Stop voicemail being used to answer calls.
Voicemail Ringback On: *48
Have voicemail ring your phone when you have any new messages. It will call when you use the phone.
Voicemail Ringback Off: *49
Switch off ringback.

Chapter 21. System Administration

21. System Administration

If necessary, the system administrator can configure you as a ‘system phone user. This allows you to perform a range of additional functions to help maintain your phone system, such as:

Checking the system and software version
Checking the time settings
Setting the date
Setting the time
Setting the time offset
System shutdown
Memory card/file system management
System alarms 21.1 Checking the System Information

Being able to check and report the system software version may be useful when reporting any potential problems to the system administrator.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight System Information. Press Select.
The system displays the following information about itself:
The system type and the level of software it is running.

The IP addresses of the two network interfaces.
The serial number of the license key.

21.2 Setting the Date

The process below can be used when the telephone system does not obtain the time and date automatically. On systems that are configured to obtain the time automatically, the option for checking the Time Server Status is available instead.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight Date. Press Select.
The current date being used by the telephone system is displayed.
Enter the required date, using the either the * or # keys to enter the / separators. To delete the previous digit or character entered press Bksp.
When a complete valid date has been entered, the display will confirm that by showing the full date and the Set soft key option.
To set the date as the new date to be used by the telephone system press Set.

21.3 Checking the Time Server Status

For systems that automatically obtain the time from a time server, this option is available in place of the Date, Time, and Time Offset functions. It allows you to check the current status of the time server and the information the system has obtained from the time server.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight Time Server Status. Press Select.
The time server information is listed. It includes the address of the time server, the current local time and the UTC time. If the phone system is configured for daylight savings then the current amount of daylight savings being applied to the local time is also shown.

21.4 Setting the Time

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight Time. Press Select.
The current time being used by the telephone system is displayed.
Enter the required time in 24-hour clock format:

Use either the * or # keys to enter the : separator.
To delete the previous digit or character entered press Bksp.

8. When a complete and valid time has been entered, the display will request confirmation by showing the Set soft key option.

9. To set the time as the new time to be used by the telephone system press the Set soft key.

21.5 Setting the Time Offset

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight Local Time Offset. Press Select.
The current offset is displayed.
Enter the offset required in hours and minutes:

To enter the : separator press either the * or # key.
To delete the previous digit or character entered press the Bksp key.
To change the offset from between positive or negative press the right arrow key.

8. When a valid offset has been entered, the Set soft key is displayed.

9. To apply the offset to the current telephone system time press the Set soft key.

21.6 Shutting Down the System

You can shut down the telephone system for a specified number of minutes. Note that this is not a polite shut-down, once you have confirmed the action, any existing calls, and services using the telephone system will start being disconnected.

The telephone system will then remain unavailable for the duration you specify, the default being 10 minutes. After the shutdown duration, it will take up to 5 more minutes for the telephone system to complete its restart.

! WARNINGS

A shutdown must always be used to switch off the system. Simply removing the power cord or switching off the power input may cause errors.
This is not a polite shutdown, any users calls and services in operation will be stopped. Once shutdown, the system cannot be used to make or receive any calls until restarted.
The shutdown process takes up to a minute to complete. When shutdown, the CPU LED and the base card LEDs 1 and 9 (if trunk daughter card fitted) will flash red rapidly. The memory card LEDs are extinguished. Do not remove power from the system or remove any of the memory cards until the system is in this state.
To restart a system when shutdown indefinitely, or to restart a system before the timed restart, switch power to the system off and on again.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to highlight System Shutdown. Press Select.
The current default timeout (10 minutes) setting is shown and can be used by pressing OK soft key. Otherwise, enter the timeout required in hours and minutes and then press the Ok soft key.

The allowable range for the timeout is from 00:00 to 24:00. Note that a timeout of 00:00 indicates infinite (no) timeout.
The Ok soft key is not displayed if the timeout entered is not within the allowed range.
To enter the : symbol in the timeout press either the * or # key.
To delete the previous digit or character entered press the left arrow key.

7. After pressing the Ok soft key, you will be asked to confirm whether you want to shut down the telephone system. Only proceed if you are sure. If you are not sure press Back.

8. If you press the Confirm soft key, the telephone system will switch itself to a shutdown state. This will disconnect all current calls and services.

21.7 Managing Memory Cards

The telephone system can be fitted with an additional memory card or cards that are used for various functions. The memory card menu allows you to check the status of the memory card or cards fitted to your telephone system and to perform a number of actions on the cards.

Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the Features soft key.
Use the up and down arrow keys to highlight Phone User. Press Select.
Use the up and down arrow keys to highlight System Administration. Press Select. If the option is not present then you may not have been configured as a system phone user by your system administrator.
Enter your security PIN (login code) and press Done.
Use the up and down arrow keys to scroll the display to the option Memory Card (IP500/IP500 V2) or File System (Server Edition). The option shown varies depending on the type of telephone system.
The menu lists the current state of the system’s memory cards and the actions that you can perform on the card.

The status of each memory card listed will be one of either No Card, Active, or Inactive. Entries are only listed for the types of cards that are supported on the telephone system to which you are connected:
- CF – This refers to the optional compact flash card that can be fitted to IP500 systems.
- System – This refers to the first SD memory card that must be fitted to IP500 V2 systems.
- Option – This refers to the second optional SD memory card that can be fitted to IP500 V2 systems.
The actions that can be performed on the memory cards are listed below the status of the card or cards. The actions available depend type of card and its current status. After selecting an action, you can then select the card on which you want the action performed and then press the Confirm soft key to start the action.
- Shut Down (IP500/IP500 V2)
  This option is available when an Active card is present. It allows the card to be made inactive.
- Start Up (IP500/IP500 V2/Server Edition)
  This option is available when an Inactive care is present. It allows the card to be made active again.
- System Backup (IP500 V2/Server Edition)
  This option is available when a System card is present and active. It allows the telephone system’s current configuration settings to be copied to a backup file on the memory card.
- System Restore (IP500 V2/Server Edition)
  This option is available when a System card is present and active. It overwrites the telephone system’s current configuration settings with those from a backup file on the card.
- Upgrade Config (IP500 V2)
  Copy configuration files from an Optional card to the System card in the system control unit.
- Upgrade Binaries (IP500 V2)
  Copy software files from an Optional card to the System card in the system control unit.
- Copy (IP500 V2)
  This option is available on systems where both a System and Option memory card are active. It copies the contents of the System card to the Option card.

21.8 Reporting System Alarms

Memory Card Failure
There is a problem with one of the memory cards used by the telephone system. Selecting Admin will take you to the system administration menu where you can check the status of the memory cards .
Expansion Failure
There is a problem with one of the external expansion modules attached to the telephone system.
Voicemail Failure
The voicemail system is not available.
Voicemail Almost Full
The voicemail system is nearly out of storage space for any new messages, prompts, or recordings.
Voicemail Full
The voicemail system cannot store any new messages, prompts, or recordings.
License Key Failure
There is a problem with the memory card used to license features and applications.
System Boot Error
The telephone system has encountered an error while restarting. ·
Corrupt Date/Time
There is an error in the date or time being used by the system. Selecting Admin will take you to the system administration menu where you can change the date and time.

21.9 Debug Mode

This topic is tagged for 9600 Series phones only.

In addition to backing up and restoring phone information, it is possible to enter a debug/troubleshooting mode on the 9608, 9611, 9621, and 9641 phones. In Debug Mode, you can save all applicable debug data in a file named nnn_report.gz, where nnn is replaced by the telephone extension, and then send that file to an appropriate server configured by your system administrator. You may wish to send a debug report for any of the following known issues:

Phone resetting
Phone going blank
Sometimes the phone goes to speaker (and other such issues that require manually resetting the phone)
Phone faces noise/distortion at the IPO user level (this tends to happen when a user slightly raise his/her voice)
Lag in displaying Caller ID when on primary Call Appearance
Freezing of phone (and other such unresponsive lock-ups)
Contact list import via USB
Color contrasts
Speakerphone quality

Enabling/Disabling Debug Mode

While the phone is on-hook and idle, press the following sequence: MUTE 2 7 2 3 8 # (MUTE C R A F T #).
Scroll down and select DEBUG. The Debug Mode menu appears.
The first item in the list is “Debug Mode.” As the Status Line indicates, press the Change soft key to change the setting of Debug Mode “On” or “Off.” Once a change has been made, the Save soft key appears.
Press Save to save the setting, or Cancel to return the setting to its previous state. You return to the previous menu.

Sending a Debug Report

While the phone is on-hook and idle, press the following sequence: MUTE 2 7 2 3 8 # (MUTE C R A F T #).
Scroll down and select DEBUG. The Debug Mode menu appears.
Scroll to the second item in the list, “Send report to server” and click the Send soft key. Applicable debug data is sent to the server specified by your administrator in a file named nnn_report.gz where nnn is replaced by the telephone extension specified during registration. Note: The option “Send report to server” is not available if the value of BRURI is null or begins with any character sequence other than “http://” or “https://”. See your administrator for more information.
If the file saves successfully, the Status Line on the display reads “Backup successful” for five (5) seconds or until the user takes any action on the telephone. If the debug report file cannot be saved, for whatever reason (for example, the server is not available or refuses request), the Status Line reads “Backup failed” for five (5) seconds or until the user takes any action on the telephone.
Pressing either the Send or Save soft keys will return you to the previous menu. However, when you press Save the telephone will conduct a reset.

Chapter 22. Menus

22. Menus

22.1 Menu Access Control

Some menu options are dynamic and only appear when appropriate. For example, the Features menu cannot be accessed when the phone is locked. Access to other menu options is controlled by your system administrator. They can set system-wide rules for which options phone users can access. They can also set specific rules for each phone user.

Even if you are restricted from accessing an option, it may still be applied to you by your system administrator. For example, the system administrator may configure call forwarding settings for you.

The system administrator can control your menu access to the following groups of functions:

Basic Call Functions: Controls whether you can access the phone’s menu options for call pickup, park, unpark and transfer to mobile
functions.
Advanced Call Functions: Controls whether you can access the phone’s menu options for do not disturb, account code, withhold number and internal auto-answer functions. In addition, the Account Code menu is only shown if the system has been configured with accounts codes.
Forwarding Functions: Controls whether you can access the phone’s menu options for forwarding and follow me functions.
Hot Desk Functions: Controls whether you can access the menu options for logging in and out.
Passcode Change: Controls whether you can change your login code (security credentials).
Phone Lock: Controls whether you can access the menu options for locking the phone and for setting it to automatically lock.
Self Administration: Controls whether you can access the Self-Administration menu option.
Voicemail Controls: Controls whether you can access the Visual Voice option through the phone’s Features menu. Your system administrator can also disable the Messages button from accessing the visual voice menus.
Group Controls: The system administrator is able to configure if you can access the Membership, State and Fallback options of a group. If you are not configured for any groups then the Group menu is not shown.
Mobility Controls: The Mobile Twinning options are only shown if you have been configured to use mobile twinning.

Menus: Menu Access Control

System Administration Controls
The System Admin option is only shown if you have been configured as a ‘System Phone’ user.

Note that restricting menu access does not restrict access using available shortcodes and programmable buttons. However, those can also be removed or added by your system administrator.
